Steel Rail-------Heavy Rail From Anna

Steel Rail-------Heavy Rail From Anna thumbnail-1
Steel Rail-------Heavy Rail From Anna thumbnail-2
Steel Rail-------Heavy Rail From Anna photo-1
Steel Rail-------Heavy Rail From Anna photo-2
US$ 1 - 1 MOQ: 20 Tons
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Grade:
U71Mn, Q235, 50Mn,
Rail Heigth:
63.5-192mm
Contact Supplier Request Quote Chat Now
Anshan Ying Yat Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard AISI, ASTM, BS, DIN, GB, JIS
Grade U71Mn, Q235, 50Mn,
Rail Heigth 63.5-192mm
Bottom Width 63.5-170
Web Thickness 5.9-20mm
Head Width 32.1*120mm
Length 6m,8m,9m,10m,12m,12.5m
Place of Origin Liaoning, China
Brand Name YY
Model Number QU70,80,100,120
Type Heavy Rail
Application Railway Rail
Weight 38kg, 43kg, 50kg, 60kg.
Secondary Or Not Non-secondary
Bolt Hole Diameter 16-31mm

Heavy rails: 38kg, 43kg, 50kg, 60kg

Steel grade: U71Mn / 50Mn and so on

Length: 12.5m

Executive standard: refer to GB2585-81/QB



We can also deal with rail processing, rail end cutting and rail straightening as per clients’ requirements.



Besides all kinds of international standard steel and iron products, we also can empolder, develop and manufacture various non-standard products, especially for some metallic products with high technical requirements & biggish manufacturing difficulty & lighter, thinner and complicated cross-section shape. We hope every organization and individual will use our service widely and contact us at any moment. We promise we will assure the manufacturing period and quality to satisfy you. Our company is highly praised for the steel and steel products exported to over 30 countries around the world.



Rail type

Theoretical weight

9kg

8.94kg/m

12kg

12.20kg/m

15kg

15.20kg/m

18kg

18.06kg/m

22kg

22.30kg/m

24kg

24.46kg/m

30kg

30.1kg/m

38kg

38.733kg/m

43kg

44.653kg/m

50kg

51.514kg/m

60kg

60.64kg/m

QU70

52.8kg/m

QU80

63.69kg/m

QU100

88.96kg/m

QU120

118.10kg/m
