Solar Water Pump MPPT Controller Without Inverter 3500W

Solar Water Pump MPPT Controller Without Inverter 3500W thumbnail-1
Solar Water Pump MPPT Controller Without Inverter 3500W thumbnail-2
Solar Water Pump MPPT Controller Without Inverter 3500W thumbnail-3
Solar Water Pump MPPT Controller Without Inverter 3500W thumbnail-4
Solar Water Pump MPPT Controller Without Inverter 3500W thumbnail-5
Solar Water Pump MPPT Controller Without Inverter 3500W photo-1
Solar Water Pump MPPT Controller Without Inverter 3500W photo-2
Solar Water Pump MPPT Controller Without Inverter 3500W photo-3
Solar Water Pump MPPT Controller Without Inverter 3500W photo-4
Solar Water Pump MPPT Controller Without Inverter 3500W photo-5
US$ 850 - 850 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
SHUILISHI
Model Number:
4PSS8-12
Contact Supplier Request Quote Chat Now
Taizhou Donghai Fishery Machine & Electrics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI/NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name SHUILISHI
Model Number 4PSS8-12
Specification Normal
Application Commercial
Output Voltage (V) DC 96V
Load Power (W) 750W
Solar Power (W) 1000W
Work Time (h) 8-24 HOURS

  low pressure water pumps



Pump Application
  • Domestic water supply
  • Livestock watering
  • Gardens or fountains
  • Pond management
  • Irrigation in horticulture & agriculture
  • Small scale service industries
  • etc.
Solar pump technical data
4PSS Series( 4" S.S impeller pump with 4"water-filled motor)
Model Voltage Power Match solar panel  Flow&lift outlet
V/DC W Power(W/PCS) VMP/Panel Max.flow Max.head (inch)
4PSS2-4 72 550 230W*3PCS 29.5VMP/PC 4m3/h 45m    1.25
4PSS2-7 96 750 230W*4PCS 29.5VMP/PC 4m3/h 60m    1.25
4PSS2-15 144 1100 230W*6PCS 29.5VMP/PC 4m3/h 95m    1.25
4PSS2-18 216 1500 230W*8PCS 29.5VMP/PC 4m3/h 145m    1.25
4PSS2-24 288 2200 230W*11PCS 29.5VMP/PC 4m3/h 185m    1.25
4PSS2-28 240 3500 230W*18PCS 29.5VMP/PC 4m3/h 240m    1.25
4PSS2-40 288 4500 230W*22PCS 29.5VMP/PC 4m3/h 300m    1.25
4PSS3-2 72 550 230W*3PCS 29.5VMP/PC 5.2m3/h 300m    1.25
4PSS3-5 96 750 230W*4PCS 29.5VMP/PC 5.2m3/h 45m    1.25
4PSS3-12 144 1100 230W*6PCS 29.5VMP/PC 5.2m3/h 85m    1.25
4PSS3-13  216 1500 230W*8PCS 29.5VMP/PC 5.2m3/h 120m    1.25
4PSS3-18  288  2200 230W*11PCS 29.5VMP/PC 5.2m3/h 160m    1.25
4PSS3-22  240  3500 230W*18PCS 29.5VMP/PC 5.2m3/h 175m    1.25
4PSS3-30 288 4500 230W*22PCS 29.5VMP/PC 5.2m3/h 215m      1.5
4PSS5-3 96 750 230W*4PCS 29.5VMP/PC 8.2m3/h 25m      1.5
4PSS5-7 144 1100 230W*6PCS 29.5VMP/PC 8.2m3/h 55m      1.5
4PSS5-10 216 1500 230W*8PCS 29.5VMP/PC 8.2m3/h 100m      1.5
4PSS5-14 288 2200 230W*11PCS 29.5VMP/PC 8.2m3/h 115m      1.5
4PSS5-18 240 3500 230W*18PCS 29.5VMP/PC 8.2m3/h 158m      1.5
4PSS5-26 288 4500 230W*22PCS 29.5VMP/PC 8.2m3/h 271m      1.5
4PSS8-2 96 750 230W*4PCS 29.5VMP/PC 14m3/h 17m         2
4PSS8-4 144 1100 230W*6PCS 29.5VMP/PC 14m3/h 37m         2
4PSS8-6 216 1500 230W*8PCS 29.5VMP/PC 14m3/h 56m         2
4PSS8-10 288 2200 230W*11PCS 29.5VMP/PC 14m3/h 92m         2
4PSS8-12 240 3500 230W*18PCS 29.5VMP/PC 14m3/h 106m         2
4PSS8-18 288 4500 230W*22PCS 29.5VMP/PC 14m3/h 148m         2
4PSS14-2 144 1100 230W*6PCS   29.5VMP/PC 22m3/h  22m         2
MPPT controller
Accessories:













Packaging & Shipping





Company Information



       Taizhou Donghai Fishery Machine & Electronics Co., Ltd. not only owns advanced process technology, automatic production flow and strict process control but also integrates the design, development, production, sales and service.



        Its leading products include high-efficiency solar energy systems, solar water pumps, AC submersible pumps, solar swimming pool pumps, 304 stainless steel shield water-filled or oil-filled submersible motors, brushless energy-saving servo motors for industrial sewing machines, silicon rectification generators, high pressure blowers, etc. Products can also be re-designed and adjusted so as to satisfy the requirements of the customers.



        In addition, the company has been certified to ISO Quality Management System and the products have passed the certifications of CE and RoHS. Its excellent brand image and good reputation have also received high praise from most of the customers. It is believed that only by grasping the core technology and innovating constantly can we produce more satisfying products.
