Application
Metering
The electric water pumps shall be lifted up and laid down vertically, and the dipping depth shall be more than 2 meters but no more than 35 meters. Four meters or more must be maintained between the electric pumps and the well bottom so that the sundries won't be involved.
Moreover, the electrode on the under-well level controllers must be one meter or more above the electric pumps to ensure that the electric pumps are complete dipped in the water when running. Security guard systems will automatically work when the voltage is too low, the current is too small, the pipe is frozen, or the impeller is blocked. Please cut it off the spare cables, and the cables must be reliably grounded.
Identification Code
eg:4SPM2-9
4 : Well dia 4"
SP: Pump Name
M:single phase,three phase without M
2 : Capacity(m3/h)
9 : Impeller's Number
Applications :
The submersible pumps are designed for delivery of water in househole confitions from wells and boreholes with inner diameter more than 100mm,as well as for delivery of water from open water bodies(rivers,lakes) and reserviors.4INCH series electric pumps may be operated in the automatic water-supply systems,be used for watering of gardens and vegetable gardens
Operating conditions :
pumped water temperature1-45
ambient air temperature 1-55
pumped water mineralization:not more than 1500g/M3
combustible,chemically active liquids
Motor :
asynchronous single-phase submersible capacitor electric motor/three phase electric motor
frequency:50Hz
voltage:200-240V ,380-415V
insulation class:F
protection degree:IP68
operation model:continuous
Other Voltage or Frequency 60Hz are available
Material
pump housing:stainless steel
impeller:Stainless steel
diffuser:Stainless steel
Shaft:stainless steel
Seal:graphite&ceramic
Moreover, the electrode on the under-well level controllers must be one meter or more above the electric pumps to ensure that the electric pumps are complete dipped in the water when running. Security guard systems will automatically work when the voltage is too low, the current is too small, the pipe is frozen, or the impeller is blocked. Please cut it off the spare cables, and the cables must be reliably grounded.
Identification Code
eg:4SPM2-9
4 : Well dia 4"
SP: Pump Name
M:single phase,three phase without M
2 : Capacity(m3/h)
9 : Impeller's Number
Applications :
The submersible pumps are designed for delivery of water in househole confitions from wells and boreholes with inner diameter more than 100mm,as well as for delivery of water from open water bodies(rivers,lakes) and reserviors.4INCH series electric pumps may be operated in the automatic water-supply systems,be used for watering of gardens and vegetable gardens
Operating conditions :
pumped water temperature1-45
ambient air temperature 1-55
pumped water mineralization:not more than 1500g/M3
combustible,chemically active liquids
Motor :
asynchronous single-phase submersible capacitor electric motor/three phase electric motor
frequency:50Hz
voltage:200-240V ,380-415V
insulation class:F
protection degree:IP68
operation model:continuous
Other Voltage or Frequency 60Hz are available
Material
pump housing:stainless steel
impeller:Stainless steel
diffuser:Stainless steel
Shaft:stainless steel
Seal:graphite&ceramic
