New Product 3W Mini Solar Light System , 2.5Ah Lithium Battery

Name: New Product 3W Mini Solar Light System , 2.5Ah Lithium Battery
Brand: INYAN SOLAR
SKU: 139571297

US$ 16 - 19 MOQ: 100 Sets

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

INYAN SOLAR

Model Number:

ISS3-2.5L

Ningbo Inyan Solar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name INYAN SOLAR

Model Number ISS3-2.5L

Specification Mini

Application Home

Output Voltage (V) 6Vdc

Load Power (W) 32Wp

Solar Power (W) 10.5V 3W

Work Time (h) 3~8 hours

Main features:

1). Built-in charge control & lithium battery, no need extra battery.

2). Mini & light, easy to carry for outside camping.

3). Overload,overheating,short-circuit,overvoltage,low-voltage,reverse PV & battery protection etc.

4). 1 x 5V USB & 3 x 6V DC outputs.

5). 4 in 1 USB charge cables (Optional).

6). 2W or 3W LED light w/5m or 10m light cables (Optional).

Technical data:

Model	ISS3-2.5L	ISS6-2.5L	ISS6-4.5L
System Specification:
Rated Output Power	15W	15W	15W
Solar Panel (Standard)	10.5V 3W(Poly)	10.5V 6W(Poly)	10.5V 6W(Poly)
	Plastic frame with stand & 3m solar cable
Solar Charging Time	5H effective sunlight	2.5H effective sunlight	4H effective sunlight
Solar Battery	7.4V 2.5Ah	7.4V 2.5Ah	7.4V 4.5Ah
	Lithium battery
Solar Charge Controller	6V 2A
AC Output	No
DC Output	36V & 1 5V USB
DC Output Current	6Vdc current ≤ 1.5A/PC, 5V USB current ≤ 0.5A
Over-load Protection	√
Over-charge Protection	√
Over-discharge Protection	√
Short-circuit Protection	√
Low-voltage Protection	√
Reverse PV & Battery Protection	√
Other Accessories(Optional)	6V 2W or 3W LED light
	3m, 5m or 10m light cable
	4 in 1 USB cables for charging mobile phones
Certificate	CE & RoHS
Mechanical Data:
Size of the System Box	L120W120H30mm
Net weight of system box	0.20kg	0.20kg	0.30kg
Size of solar panel	L255W140H16mm	L225W188H20mm	L225W188H20mm
Net weight of solar panel	0.40kg	0.60kg	0.60kg
Size of Battery	L40W70H20mm	L40W70H20mm	L80W70H20mm
Net weight of battery	0.10kg	0.10kg	0.20kg
