Factory Supply coal ball press machine
Contact Informations:
Contact Person: Ms. Amy
Mobile/WhatsApp/Wechat/Line: 0086-18092951870
Skype: amysilkroad
Introduction of coal charcoal briquette machine:
This machine is mainly used for high-density metal scrap (scrap iron, copper scrap, aluminum
scrap, etc.), granular powder metal powder (iron powder, aluminum powder, copper powder, lead powder, etc.) , metallurgical additives, sponge iron, etc., without adding any binder pressed into the case of cylindrical cakes of high-density block (weight 2-8 kg), the cake density of up to 5T/M3
block above (the different raw materials, press out the cake block density and not quantity is not
the same), pressed into the cake pieces can be directly cast furnace use.
1)Raw material size should be smaller than 3mm.
2)The best moisture for briquetting is 10-15%.
Application of coal charcoal briquette machine:
The briquette machine have been mainly used in home fire, heating with anthracite honeycomb made of cylindrical briquettes. Previously been processed into the coal sphere slightly larger than ping-pong, and later the coal processed into one cylinder, and marked with a number of holes inside
the cylinder, because it can increase the surface area of coal, so that the full combustion of coal, to reduce resource waste.
Working Principle of coal charcoal briquette machine:
This series of briquette machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
Feature of coal charcoal briquette machine:
Our machine has features of high productivity, significant energy-saving, easy to use, safe,
reliable, easy to maintain, use low-cost, is the ideal honeycomb processing equipment.
It can process Circular honeycomb, a variety of sizes, number of holes can meet the specifications required.
Parameter of coal charcoal briquette machine:
Type |
Capacity (t/h) |
Motor power |
Roller width (mm) |
Roller material |
SR-290 |
1-2 |
5.5 |
220 |
65Mn |
SR-360 |
2-4 |
7.5 |
250 |
65Mn |
SR-400 |
6-8 |
11-15 |
280 |
65Mn |
SR-500 |
8-11 |
18.5-22 |
300 |
65Mn |
SR-650 |
13-18 |
20-30 |
336 |
65Mn |
SR-750 |
18-25 |
45 |
400 |
65Mn |
SR-850 |
25-35 |
75 |
500 |
65Mn |
SR-1250 |
40-70 |
130 |
650 |
65Mn |
Remark |
all the capacity of briquette machine is depend on the different material. The above just for your reference. |
|||
If you want this machine, please supply the following information:
1. What is your raw material and its size? If the size is less than 3mm,don't need to use crusher,if bigger,we will match crusher for you.
2. What is the final briquette shape and size you want? The shape can be round, pillow and square, the size can be 25~60mm,you can choose the one you prefer.
More photos of coal charcoal briquette machine:
Other Charocal Coal Briquette machine:
