Industrail PSA Oxygen Generator
O2 generator generates gaseous oxygen of a purity of 90 % - 95 % on the basis of the adsorption principle PSA (Pressure Swing Adsorption). The PSA process separates the naturally in ambient air existing oxygen (21 % oxygen, 78 % nitrogen, <1 % noble gases and other gases). This is an unambiguous physical process. The compressed air passes a molecular sieve, which adsorbs nitrogen at a high pressure and releases it at a low pressure. The O2 generators are widely used for oxygen aeration active mud processes, re-aeration of surface water, fishes breed aquatics, industrial oxidation process, humid oxygenation.
| Model | O2 Output | O2 Purity | Outlet Pres | Rate Power | Dimension |
| (l/min) | (MPa) | (kW) | (OxyGen/AC: cm) | ||
| OX-5L | 5 | 93%±5 | 0.2 | 0.66 | 55*40*76 |
| OX-10L | 10 | 93%±5 | 0.2 | 1.2 | 55*40*95 |
| OX-15L | 15 | 93%±5 | 0.2 | 2.2 | 55*40*116 |
| OX-20L | 20 | 93%±5 | 0.6 | 2.85 | 120*90*180 |
| 125*50*90 | |||||
| OX-30L | 30 | 93%±5 | 0.6 | 4.65 | 170*100*160 |
| 125*50*90 | |||||
| OX-40L | 40 | 93%±5 | 0.6 | 6.6 | 175*142*160 |
| 132*55*120 | |||||
| OX-50L | 50 | 93%±5 | 0.6 | 8.55 | 175*142*190 |
| 132*55*120 | |||||
| OX-60L | 60 | 93%±5 | 0.6 | 8.55 | 185*142*1900 |
| 132*55*120 | |||||
| OX-80L | 80 | 93%±5 | 0.6 | 11.6 | 200*142*190 |
| 132*65*120 | |||||
| OX-100L | 100 | 93%±5 | 0.6 | 15.6 | 200*142*190 |
| 150*125*130 | |||||
| OX-10N | 167 | 93%±5 | 0.6 | 20.1 | 2200*1500*2200 |
| 900*900*1120 | |||||
| OX-20N | 334 | 93%±5 | 0.6 | 31.6 | 2600*1600*2500 |
| 900*900*1120 | |||||
| OX-25N | 418 | 93%±5 | 0.4 | 38.5 | 2600*1600*2500 |
| 900*900*1120 |
