abandoned/ obsolete/ waste wood pallet/ tray crushing machine/
architectural templates grinder machine
Template grinder introduction
Template mill has been the focus of our research and development products, according to market demand for building templates crushing and develop a new generation kind of broken plate special. It is mainly the work platform, feed the main part of the pressure roller and the conveyor, etc;
Feed conveyor: Place to be broken plate type timber;
Feed pressure roller: control the feed rate and the holding plate and not the feed material slippage does not occur;
Spiral crushing roller: uniform welding on the roller cutter in the circumferential direction, in the circumferential direction of the crushing roller to ensure that a consistent force in time;
Broken plates having a feed and fragmentation simultaneously, to achieve uniform broken; feed pressure roller adopt UCK series bearing plus spring-loaded mechanism that can adapt to different sheet thicknesses broken; feed pressure roller and grinding roller adopts different power systems, easy to control.
Because of reasonable design, compact, safe, durable, high production efficiency, after promoting the use of good effect, low noise, simple structure, compact layout, the price is cheap, stable, low energy consumption, high yield, good product quality crushed low processing cost.
machine parameters
Model | Power(kw) | Inlet size(mm) | capacity(t/h) |
YWMF-800 | 55+ (2.2*3) | 850 | 3-4 |
YWMF-1000 | 75+ (2.2*3) | 1050 | 5-7 |
YWMF-1300 | 110+ (2.2*3) | 1350 | 7-9 |
YWMF-1500 | 132+(2.2*3) | 1550 | 10-15 |
machine features
1, the feed conveyor: Place to be broken plate type timber,
2, the feed pressure roller: control the feed rate and the holding plate and not the feed material slippage does not occur,
3, spiral crushing roller: on a roll in the circumferential direction uniform welding cutter, crushing roller in the circumferential direction to ensure that the time that is consistent with force,
4, the template having a feed and broken broken synchronized to achieve uniformity broken,
5, the feed pressure roller adopt UCK series bearing plus spring-loaded mechanism that can adapt to different thickness of the plate Broken,
6, feed pressure roller and grinding roller adopts different power systems, easy to control.
pls feel free to contact me
