soap nuts cracker/ cracking machine
1. machine introduction
tea Seed peeling machine is specialized equipment for seed shelling, machine set seed peel, shell kernel separation in one, it has a simple structure, easy operation, low power consumption, low noise characteristics. Sheller seed with a compact, easy to operate, reliable performance, high efficiency peel, sorted, low loss advantages. Seed sheller structure: The machine has a hopper, roller lever pattern, shelf strips gravure, fans, gravity sorting screen, composed air conveyor and other part of the structure is simple and compact, simple operation, stable performance, safe and reliable. good durability.
Mountain tea seed peeling machine works: seed by the wind sent the feeding device (or artificial feeding) into the feed hopper into the front roller, the use of grain and squeeze rubbing force plate is rotated between the curvature of the gate will seed kernels stripped shell, stripped After tea seed kernels and shells falling at the same time by the former arc gate, through the duct from the fan wind will blow most seed shell outside the machine, but not yet part of the seed kernels and peeled seed fell along with the proportion of small fruit sorting on a sieve, seed kernels after sorting by sorting screen surface line, through a mouth out of benevolence. No seed small fruit peel, by sorting the sun face down, through back entrance and exit into the lifting device, the breeze lifting device into the rollers after the second shelling, kernels and shells after peeling after falling arc gate again by the winnowing fan, gravity sorting screen selection, and so forth, you can achieve all sheller.
Seed peeling machine Note:
1. Before use, you should first check whether fasteners tightened, rotating parts are flexible, whether each bearing lubricating oil, the machine should be placed on a stable surface.
2. Before use, check the power switch must be in the off position.
3. After starting the motor, the rotor should be referred to in the same direction and turn on the equipment. To idle a few minutes to observe any abnormal sound, in normal operation, the only uniform feed.
3. machine parameters
Model |
Capacity |
Size of overall |
Size of package |
Weight |
power |
|
YWT-450A |
|
|
|
170kg |
|
YWT-450B |
2-5t/day |
185*70*120cm |
160*75*100cm |
170kg |
2.2kw/380v |
|
YWT-600A |
5-10 t/day |
250*90*145
|
|
|
5.5kw/380v |
pls feel free to contact me
