3-15L oxygen making machine / psa oxygen generator / oxygen generator for room
3-15L oxygen making machine / psa oxygen generator / oxygen generator for room
Descriptions:
1. Simple structure, easy to operate, and stable oxygen output.
2. Material: zeolite/alumina; each unit can work independently, and oxygen output can reach to 3-10 LPM or higher.
3. With chiller for cooling air, no need additional refrigerant dryer for reducing cost.
4. Oxygen purity can up to 90+5%. Two oxygen cylinders exchange working, auto drain water, nitrogen and other impurities output.
5. Parts with shipping: chiller, fan and air inlet pipe.
6. Oxygen outlet pressure: 0.06-0.08Mpa.
Rational construction
Modular construction is the main points of our molecular sieve. Through the different combination of oxygen units, the oxygen output can be from 1 LPM to 160 LPM, even higher.
Easy to control
Each unit can be work independently, according to the different oxygen output requirement. And free control for the different unit combinations. So that, it can be suitable used for the standardization of products. Meanwhile, maintenance will be more convenient.
The oxygen output is stable and continuously
Low-pressure oxygenproduction working pressure less than 3 KG.
Item |
Unit |
NTOX3AL |
NTOX5AL |
NTOX7.5AL |
NTOX10AL |
NTOX15AL |
Oxygen output |
LPM |
3 |
5 |
7.5 |
10 |
15 |
Oxygen concentration |
% |
90%±3% |
90%±3% |
90%±3% |
90%±3% |
90%±3% |
Air flow rate |
LPM |
36-45 |
60-75 |
90-115 |
90-115 |
180-200 |
Pressure(inlet) |
Mpa |
0.14-0.18 |
0.14-0.2 |
0.15-0.21 |
0.18-0.25 |
0.35 |
Pressure(outlet) |
Mpa |
0.06-0.08 |
0.06-0.08 |
0.06-0.08 |
0.06-0.08 |
0.06-0.08 |
Temperature |
℃ |
indoor temperature |
||||
Relative humidity |
% |
≤ 70%±10% |
||||
Noise |
Db |
≤60 |
≤60 |
≤60 |
≤60 |
≤60 |
Dimension |
mm |
dia200×310 |
dia200×430 |
dia200×500 |
dia200×560 |
dia200×880 |
Net weight |
kg |
15.70 |
18.30 |
19.30 |
30.60 |
32.5 |
Quality control:
- Every procedure has personnel inspection.
- All the products must be tested and qualified before packaging.
