High quality ALYD-B Silicon steel door aluminum cutting machine for 45 degree
1. Description for aluminum cutting machine:
Our company developed this new and improved aluminum angle cutting machine, this machine is controlled by imported pneumatic control system, with wonderful processing effect, the knife speed is stable and smooth. It is suitable for cutting aluminum alloy frame, edge banding, picture frames, doors and windows, aluminum 45 °, 90 °,and equipped with standard ruler, accurate positioning; foot control, press material positioning mechanism; automatic exhaust waste structure, much easier for operation, also safe and fast. The working table is adopt imported steel plate, worktop thickness is 100mm and surface grinding, makes the cutting high precision and machine durable.
2. Technical parameter for aluminum cutting machine:
Model: ALYD-B
Work form: pneumatic, electric.
Operate way: semi automatic
Cutting speed: adjustable
Air pressure needed: 4-8kg/square
Max cutting distance: 150mm
Max cutting thickness: 95mm
Cut angel: 45 degree, 90degree.
Voltage: 220V(380V or customized)
Motor power: 1.5KW
Motor: Copper wire motor second-level motor
Saw blade rotating speed: 4500r/min
Weight: 160kg
Install the saw blade axis diameter: 25.4mm
Aluminum alongside ruler: L1030mm*W35mm*H45mm(2 pcs)
Can install any saw blade with size about 33cm-40cm.
Dimension: L*W*H(700*700*900mm)
Optional parts: 1. Can add cradle.
2. Can add Cutting fluid injection device.
3. Can add gas pushed oil device.
3. Images for aluminum cutting machine:
