Product Details
| Condition | New | Type | Fabric Dust Collector | |
| Efficiency | 99.9% | Minimum Particle Size | 0.5 Micron | |
| Place of Origin | Jiangsu, China | Brand Name | WEIFENG | |
| Model Number | DMC | Dimension(L*W*H) | Model | |
| Weight | 1~84ton | Certification | CE,ISO,ISO9001,ROHS | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Dust collector dust collector system dust collector machine
Production Description :
The baghouse dust collector is a kind of dry dust filtering device. It applies to capture fine, dry, non-fibrous dust. Baghouses (also called pulse jet baghouse, pulsejet dust collectors, etc...) are self contained, fully automated where needed. We also supply and install ducting, access platforms, ventilation and instrumentation. Baghouses are engineered for dusts of 3 microns and larger, in the following applications:
- Woodworking
- Cement production
- Powder processing
- Steel melting
- Material handling
- Primary metals, including steel-making
- Metals fabrication: grinding, sawing, sanding, polishing
- Papermaking
- Mixing and blending options
- Mining
- Foundries
- Glass Plants
- Battery Plants
- Universities
- ......
We offer a full range of collector designs and media choices to solve the toughest pollution control problems involving high temperatures, pressures and corrosives.
Dust collector dust collector system dust collector machine Technical Parameters:
HCMC
Model | Weight(kg) | Filtering area(m2) | Dimension(mm) | Air volume m3/h |
HCMC-1.5x32 | 1264 | 20.352 | 1626x1277x4176 | 1831.68 |
HCMC-1.5x50 | 1678 | 31.8 | 1986x1457x3776 | 2862 |
HCMC-1.5x72 | 1972 | 45.792 | 2346x1687x4171 | 4121.28 |
HCMC-1.5x98 | 2233 | 62.328 | 2706x1917x4171 | 5609.52 |
HCMC-1.5x128 | 2456 | 81.408 | 3066x2117x4171 | 7326.72 |
HCMC-1.5x162 | 3466 | 103.032 | 3516x2297x4671 | 9272.88 |
HCMC-1.5x200 | 3598 | 127.2 | 3876x2477x4671 | 11448 |
HCMC-1.5x242 | 4527 | 153.912 | 4427x2677x4751 | 13852.08 |
HCMC-1.5x288 | 5016 | 183.168 | 4787x2907x4971 | 16485.12 |
HCMC-1.5x338 | 5414 | 214.968 | 5147x3147x5271 | 19347.12 |
HCMC-2.5x98 | 2489 | 103.88 | 2706x1917x5171 | 9349 |
LDMC--A type:
| Specification Item | 1 | 2 | 3 | 4 | 6 | 7 | 8 | 9 |
| Air flow (m³/h) | 65000 | 97500 | 130000 | 130000 | 195000 | 260000 | 325000 | 390000 |
| Filter area (m²) | 1084 | 1626 | 2168 | 2168 | 3252 | 4336 | 5420 | 6504 |
| Number of baghouse | 2 | 3 | 4 | 4 | 6 | 8 | 10 | 12 |
| Specification of filter | Ø160×6000 | |||||||
| Number of baghouse filter | 360 | 540 | 720 | 720 | 1080 | 1440 | 1800 | 2160 |
| Outside size(m) L×W×H | 6.3 ×5.7 ×13.8 | 9.3 ×5.7 ×13.8 | 12.3 ×5.7 ×13.8 | 6.3 ×11.4 ×13.8 | 9.3 ×11.4 ×13.8 | 12.3 ×11.4 ×13.8 | 15.3 ×11.4 ×13.8 | 18.3 ×11.4 ×13.8 |
LDMC--B type:
| Specification Item | 1 | 2 | 3 | 4 | 6 | 7 | 8 | 9 |
| Air flow (m³/h) | 81200 | 121900 | 162500 | 162500 | 243800 | 325000 | 406350 | 487620 |
| Filter area (m²) | 1355 | 2030 | 2710 | 2710 | 4064 | 5418 | 6772 | 8127 |
| Number of baghouse | 2 | 3 | 4 | 4 | 6 | 8 | 10 | 12 |
| Specification of filter | Ø160×7500 | |||||||
| Number of baghouse filter | 360 | 540 | 720 | 720 | 1080 | 1440 | 1800 | 2160 |
| Outside size(m) L×W×H | 6.3 ×5.7 ×15.3 | 9.3 ×5.7 ×15.3 | 12.3 ×5.7 ×15.3 | 6.3 ×11.4 ×15.3 | 9.3 ×11.4 ×15.3 | 12.3 ×11.4 ×15.3 | 15.3 ×11.4 ×15.3 | 18.3 ×11.4 ×15.3 |
(It's only for your reference, detailed dust collector will be designed according to your condition, so if you're interested, please do not hesitate to contact me. )
Photos :
Our service for Dust Collector Dust Collector Machine:
4. We can provide customers with free English foundation drawing, installation drawings, manuals, maintenance manuals and parts drawings.
