Turn Key Complete 1-10t/h Chicken and Cattle Feed Pellet Making Machine Line

Turn Key Complete 1-10t/h Chicken and Cattle Feed Pellet Making Machine Line photo-1
Turn Key Complete 1-10t/h Chicken and Cattle Feed Pellet Making Machine Line photo-2
Turn Key Complete 1-10t/h Chicken and Cattle Feed Pellet Making Machine Line photo-3
Turn Key Complete 1-10t/h Chicken and Cattle Feed Pellet Making Machine Line photo-4
Turn Key Complete 1-10t/h Chicken and Cattle Feed Pellet Making Machine Line photo-5
US$ 4,800 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
LYWF
Payment & Shipping
Payment Methods:
Port of Shipment:
china port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name LYWF
Model Number SZLH508
Type Feed Pellet Machine
Voltage 380V
Power(W) 110KW
Dimension(L*W*H) 5500*2200*2100MM
Weight 3000 kg
Certification CE ISO SGS
Warranty 1 Year, Two years
After-sales Service Provided Engineers available to service machinery overseas

turn key Complete 1-10t/h chicken and cattle feed pellet  line



Advantage:

1.This feed pellet machine is equipped with screw feeder controlled by FC inverter with permanent magnet to removing iron impurities.
2. Stainless steel conditioner makes even retention and sufficient cooking effect.
3. Gear directly-connecting driving is adopted for high accuracy and efficiency. The output can increase 20% comparing to feed pellet machine driven by belts.

4. High quality bearings(NSK),motor( Siemens or China top brand-Wannan ) is adopted to makes operation smoothly.

5. Main gear and pinion shaft adopt the carbonizing quenching with high accuracy, to ensure smooth driving, low noise and long service life.

6. The ring die& roller assemblies are quickly assembled and disassembled.

7. Applicable for all kinds of high grade animal/livestock/aqua feed. Sinlge, double or three layers of conditioner is optional.

8. Speed-adjust feeding, adopted by this feed pellet machine, can control the feeding capacity correctly to fit for different and meet the production requirement of pellets with different diameters.



Technical Parameters:

Model

Main Power
(kw)

Capacity
(t/h)

Feeder Power
(kw)

Conditioner Power
(kw)

Die Diameter
(mm)

Feed Pellet Size
(mm)

SZLH250

15

0.5-1

0.55

2.2

250

2-18

SZLH320

37

2-5

0.75

2.2

320

2-18

SZLH350

55

2-7

0.75

3

350

2-18

SZLH400

75/90

3-12

1.1

4

400

2-18

SZLH420

90/110

3-14

1.5

5.5

420

2-18

SZLH508

110/132/160

4-20

1.5

7.5

508

2-18





turn key Complete 1-10t/h chicken and cattle feed pellet making machine lineturn key Complete 1-10t/h chicken and cattle feed pellet making machine lineturn key Complete 1-10t/h chicken and cattle feed pellet making machine lineturn key Complete 1-10t/h chicken and cattle feed pellet making machine lineturn key Complete 1-10t/h chicken and cattle feed pellet making machine lineturn key Complete 1-10t/h chicken and cattle feed pellet making machine lineturn key Complete 1-10t/h chicken and cattle feed pellet making machine line
