Small electric dried chili grinder machine price
Description
This grinding machine is a professional powder grinding equipment, which is used for grinding various grains, dry spices, branches, chemical materials, dry herbs, tree roots, barks, and some other herb and brittle materials.
Detailed application examples
1. Sesame seed, walnut, rice, beans, mung beans, peanuts, lotus seed, barley, buckwheat, sugar, coffee, cocoa beans, etc.
2. Herb leaves, herb seeds, herb roots, shells, almonds, poria cocos, red jujube, gordon euryale seed, medlar, hawthorn, radix polygoni multiflori, red beans, donkey-hide gelatin, frankincense, dodder, angelica, dangshen, astragalus, membranaceus, etc.
3. Pepper, Chinese prickly ash, star anise, cinnamon, etc.
Specification
| Model |
Capacity (kg/h) |
Fineness (mesh) |
Power (kw) |
Rotating speed(r/min) |
Size (mm) |
Weight (kg) |
| AZEUS-G200 | 30-120 | 10-120 | 2.2 | 4200 | 480*520*1040 | 80 |
| AZEUS-G300 | 60-200 | 10-120 | 5.5 | 4200 | 750*600*1260 | 180 |
| AZEUS-G400 | 80-300 | 10-120 | 7.5 | 4200 | 780*700*1350 | 260 |
| AZEUS-G500 | 100-500 | 10-120 | 11 | 4200 | 800*900*1550 | 320 |
| AZEUS-G600 | 500-1000 | 10-120 | 15 | 4200 | 1200*1000*2000 | 520 |
Working principle of this chili grinder
This grinder machine works by of high-speed relative motion between movable and fixed fluted disc, the material being crushed through impact and friction of the fluted disc. The crushed materials can be discharged directly from the grinding chamber, and flow out from the outlet.
General materials will be collected in a cotton bag(as following), the air will escape from the tiny hole without wasting any crushed materials, thus no polluting, no wasting.
Features of this chili grinder machine
- It is fully made of 304 stainless steel, which is durable and easy to clean.
- Different fineness of final powder can be achieved by changing difference mesh size sieves.
- Voltage of this machine can be customized according to customers' requirement.
- It has simple and sturdy construction, with low noise, high grinding efficiency, and excellent grinding effect.
- All the tooth space inside the grinder chamber is precisely designed and manufactured, to get a smooth surface, which is quite easy to clean and maintain, making the production of food industry, chemical industry and pharmaceutical industry meet the national standard and the sanitary requirement of Good Manufacturing Practice.
Images of this chili grinder
Inside
Operation demonstrations for customers
Package and delivery
If any questions or needs about our chili grinder, or other related food machines, please send me inquiry here or contact me via the following information:
Contact person: Grace
Email: joywan(at)
WhatsApp: 0086 15617773482
Skype: gracexie55
