plastic pelletizer/plastic granulator/plastic recycling granulator
This pelletizing line,recycling PP PE PET PVC, film ,bags, flakes, make them into pellets.
Process flow of plastic pelletizer/plastic granulator/plastic recycling granulator :
Conveyor→ raw material compactor(feeder)→ Extruding system→ Die-head and High speed Net exchanging system→ water ring pelletizing system/noodle type pelletizing system→ dewatering machine→ vibrating sieve→ Air Blower → Storage hopper
Main technical data of plastic pelletizer/plastic granulator/plastic recycling granulator
:
Extruder |
AMS90 | AMS120 |
AMS150 |
AMS180 |
AMS200 |
Main Motor Power |
55KW | 75kw |
110kw |
185kw |
260 KW |
Production capacity |
150KG/H | 150-250kg/h |
300-400kg/h |
450-800kg/h |
1000kg/h |
Thecnical parameters of plastic pelletizer/plastic granulator/plastic recycling granulator :
Model |
L/D |
Output |
Speed of Screw Rotation |
Power |
Center Height |
AMS-50/33 |
33:1 |
20-80 kg/h |
12.5-130 r/min |
37kw |
1000 mm |
AMS-65/33 |
33:1 |
80-150 kg/h |
33-130 r/min 20-120r/min |
45kw |
1000 mm |
AMS-75/33 |
33:1 |
120-280 kg/h |
20-120 r/min |
55kw |
1000 mm |
AMS-90/33 |
33:1 |
150-450 kg/h |
33.3-110 r/min |
75kw |
1000 mm |
AMS-120/33 |
33:1 |
300-600 kg/h |
20-100 r/min |
90kw |
1200 mm |
AMS-150/33 |
33:1 |
450-700 kg/h |
7-80 r/min |
110kw |
1200 mm |
AMS-180/33 |
33:1 |
600-800kg/h |
7-80 r/min |
185kw |
1200 mm
|
AMS-200/33 |
33:1 |
800-1000kg/h | 7-80 r/min |
260kw | 1200 mm |
