Best price for diesel generator set 50 kva
Diesel generator set is made from engine, generator and control system.
Diesel is the prime mover for diesel generator,it is quick start, easy operation and maintenance,low investment, strong adaptability to the environment.
Model |
TP-10000 |
TP12000 |
Rated frequency(Hz) |
50/60 |
50 60 |
Rated output power kVA |
9/10 10/11 |
10/11 11/12 |
Max. power kVA |
10/11 11/12 |
11/12 12/13 |
Rated voltage V |
230/240 230/400,240/416 |
230/240,230/400 240/416 |
Rated current A |
38.1/41.7,14.4/15.3 |
43.5/45.8 15.9/16.7 |
Phase No. |
Single/Three |
Single/Three |
Power factor |
0.9/0.8 |
0.9/0.8 |
Insulation |
F |
F |
Pole No. |
2 |
2 |
Exciting way |
self-excitation,brush,constant voltage(with AVR) |
self-excitation,brush, constant voltage(with AVR) |
Panel type |
Singel-phase socket,wiring ternimal/three-phase socket,three-phase socket |
Singel-phase socket,wiring ternimal/three-phase socket,three-phase socket |
DC12V output |
12V, 8.3A |
12V, 8.3A |
DimensionsL(mm) |
870*630*700(half-closed) |
1090*670*910mm(silent) |
Net weight Kg |
195(half-closed) |
259(silent) |
Noise 7mdB(A) |
82 |
70 |
Engine model |
R2V820 |
R2V840 |
Type |
V-twin,two-cyclinder,four-stroke, DI |
V-twin,two-cyclinder,four-stroke, DI |
Total displacement(ml) |
812 |
838 |
Cooling way |
Air-cooled |
Air-cooled |
Lubricating way |
Pressure & splashing |
Pressure & splashing |
Starting way |
Electric |
Electric |
Lubricating oil capacity L |
1.7 |
2.3 |
Starting motor capacity V-kW |
12V 1.4kW |
12V 1.4kW |
Dynamo capacity V-A |
12V 8.3A |
12V 8.3A |
Battery capacity V-Ah |
12V 45AH |
12V 45AH |
Fuel consumption under full loading L/H |
3.0/3.7 |
3.5/4.0 |
Fuel tank capacity of the generator L |
25(half-closed),63(silent) |
25(half-closed),63(silent) |
Continuous operation time of the generator H |
8.3/6.7 (half-closed),21/17(silent) |
7.1/6.5 (half-closed),18/15.7(silent) |
1. Silent, low noise (about 70 dB / 7m)
2. Compact structure with strong output power (lightest and smallest among the diesel generator sets with compatible output)
3. Intelligent control panel and full automatic generator protection system.
4. Steady frequency-governing ratio ≤ 3%, complying with military standard
5. Automatic Voltage Regulation for maintaining steady voltage
6. Unique Patent design for separate cold / heat wind passage, ensure low inner housing temperature, stable output and good reliability
Notes:
---Intelligent Control panel
With the new-type intelligent control panel we adopt, the operator can know the real working condition of the
generator from panel reading. There are more than ten protections of the generator in the panel, such as protections of
frequency, voltage, current, low oil pressure, low fuel level, and electric fan adjusting the temperature automatically when inner-housing temperature is high, and automatic unload before engine stopped each time etc.
---ATS
Our company can fit ATS based on customer requirement, which can make the generator be automatic operation without the operator on the spot.
When city power net breaks down, ATS can deliver the signal in shortest time to the generator for starting. When city power net is recovered,
ATS can shift the power from the generator to city power net.
