Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | SOLON |
Model Number: | SL420 | Voltage: | 380-415v, 380-415V | Power(W): | 95.2kw |
Dimension(L*W*H): | 2800*1300*2100mm | Weight: | 3.2t | Certification: | CE/ISO |
Warranty: | 12months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Competetive Price rice husking mill/pellet mill
Brief Introduction:
A. The machine is Ring Die pellet processing one.
B. It can not only pelletize sawdust, stalks and straw, but also process forage and fodder for animals.
C.The raw materials, also feedstock, cover sawdust, twigs, straw, rice husks, peanut shells and so on
D.The range of diameter of pellets: 6-12mm, with pellet density of 1.1
1.3t/m³ and moisture content of ≤8%;
Special Features:
1. Main drive adopts high accurate gear drive, with an output of about 20% higher than belt drive, and the die adopts the quick removing clamps.
2. The drive part of the machine including motor optimize the high quality world famous bearings, which ensure high efficient and steady driving with low noise.
3. The imperative feeder device is adopted, which making the machine operate smoothly as the material like wood sawdust, rice straw is very light, so they are needed to be pushed into pelletizing chamber by force.
4. The feeder adopts the frequency-conversion speed regulating control to guarantee the quality of wood pellet.
5. The alloy steel die is made by international advanced German gun drill and American vacuum furnace, has long service life and ensure smoothly pelletizing and high quality.
6. The international advanced compensation type flexible coupling is of novel and compact structure, safety, low noise and less trouble.
7. Permanent magnet device can remove impurities in the pelletizing process.
Technical Parameters:
Model | Capacity(t/hr) | Motor | Ringdie Diameters | Pellet Size |
SL320 | 0.2-0.4t | 37+2.2+0.75 | 320mm | 6-8 |
SL350 | 0.4-0.6t | 55+3+1.1 | 350mm | 6-8 |
SL420 | 0.8-1.3t | 90+5.5+1.5 | 420mm | 6-12 |
SL508 | 1.3-1.8t | 110+5.5+2.2 | 508mm | 6-12 |
Main Spare Parts:
1.The materials for ring dies can be stainless steel and alloy steel,the life span will be 600-800h and 300-500h processing time.
2.The roller covers also are alos made from high-quality alloy steel with higher thickness.
Pellets Sample:
1. Efficient.--Wood pellets are an efficient source of heat with high combustion vablue,like pine is 4300-4500KA,olive wood will be 4500ka and straws are 3700-3800.
2. Cost-effective--Wood pellets are economically competitive with home fossil fuel options and electric heat.
4. Environmental friendly--Wood pellets are a sustainable fuel source,the ash producing is lower than coal and log/firewood,except rice straws pellets(max8%),the other will be lower to 0.9%.
5. Renewable. Wood pellets are a biomass product made of wood waste or other forest waste.
The raw materials can be waste pallets,veneer,branches,debarks and so on.
6. Broad application. Wood pellets can be used in a lot of appliances such as stoves, furnaces, boilers and other heating systems.
Factory Showing:
We take "5S" Management Method to keep the facroy processing.
Project Ever Built:
For the complete pellet processing line,usually we need to knowthe capacity, raw materials,moisture,pellet size,packing size,warehouse size and power supply ability and so on.
Flat Die Pellet Mill:
