Honeycomb 5090 Evaporative Cooling Pad Air Conditioner Spare Part

FOB Price

USD $1 - $150 / Twenty-Foot Container

1 Twenty-Foot Container(Min.Order)

Supply Ability 10 Twenty-Foot Container per Month
Port Fuzhou
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Fujian, China

Brand Name:

ESC

Model Number:

ESC5090

Product Description

Honeycomb 5090 Evaporative Cooling Pad Air Conditioner Spare Part

Characteristics:
1. It is made from special paper with honeycomb structure. There are two types of

wave heights: 5mm and 7mm, and the corrugation is 45° × 45° Interweaving. Adopt

new-generation polymers and space crosslink technology for high water absorption,

high water proof, mildew-resistance and long service life.

2. The evaporation area is bigger than the surface, with cooling efficiency above 80%.
3. This product contains no surface active agents, absorbing water naturally, diffusing

at high speed, with lasting effectiveness. A drop of water is completely diffused within

4-5seconds, which is exceed the national specification standards. The height of natural

water absorption is 60~70mm/5min; 200mm/hour, which is fully up to international

industrial standards.
4. It contains no phenol or such chemical substances which are easy to cause skin

allergies. It is non-toxic, harmless, green, safe, energy-saving, environmental protection,

economical and applicable.

Product:

Feature:

Specification:

Specification	7090	6090	5090
Height(mm)	570 410 1500 1800 2000	570 410 1500 1800 2000	570 410 1500 1800 2000
Width(mm)	835 835 600 400 300 200	835 835 600 400 300 200	835 835 600 400 300 200
Thickness(mm)	90 100 150 200 300	90 100 150 200 300	90 100 150 200 300
Ripple height(mm)	7	6	5
Ripple angle	45*45	45*45	45*45

CE Certificate:

Product Line:

Main functions of this movable type:

1. Quiet, energy-saving. Convenient, move with caster.
2.3 gears speed: Strong, medium, weak
3. High-tech LCD-Display. Microcomputer Intelligent remote control.
4. Large-capacity water tank, about 12 hours continuous operation
5. Antimicrobial silver ions. Fashion design, tempered glass casing with flower pattern.

FAQ:

Q: Are you a trading company or a factory ?
A: We have factory with more than 10 years experience.

Q: Why your price more expensive than other Chinese suppliers?
A: Our material we use is much better than other suppliers.

  1.For all axial flow fans , and screws all use good quality stainless steel , won't be rusted .

  2. For plastic products we all use new material to make sure the products can be long use .

  3. All our products  we use China famous motor brand , the motor can 1 year guarantee ,
   with a correct using , the motor life can be more than 10 years.

Q: What voltages you can do , if you can make special voltages ?

A: Almost all kinds of voltages we all can make , but for special voltages , we have a big MOQ and maybe

    price will be a little higher . Our normal voltage is 380V 50HZ 3phase .

Q: Can you cheaper ?
A: We have many quality stage products for client choose , different stage price will be different , if you

    really want low price we will suggest you choose lower stage product , in our company , we don't have

    bad quality products , you can reassure about the quality .

Q: I want to use our own brand , is it ok?
A: Of course it's OK , we can make OEM products and also can provide our own brand products ,

    it's all by your request .
