Specifications
pellet millscapacity 0.5-3T/H
good quality
pellet mills ffaith-group
Pellet mills
Specification of 1.It is widely used to make pellets from light substance, such as wood chips, sawdust, straw, pasture, chrysanthemum, palm leaf and so on;
2.The pellet mills especial structure makes materials conveyed evenly,
it is specially designed for pellet of light substance with the density of 0.3-0.6g/ cm3;
3.The Feeder, conditioner and chute are made of stainless steel with long service life;
4.It is with magnet and over load protection system, which protects the machine during production;
5. complete wood pellet production line has a variable speed controller to meet different
outputs requirements;
6.It makes gear directly-connecting as the driver, and is with quick release die fixed by clamps,
which will increase the output by 15% when compared to a machine with a belt conveyor;
7.The bearing and oil seal in the main drive are imported from Japan to ensure highly efficient,
stability and high quality;
8.The alloy steel die is with international advanced equipment and techniques, and has long service
life, and can make slippery pellets of the highest quality.
Features of :
1.Main driving is high accuracy gearbox and high output
2.High efficiency driving, stable and low noise
3.Fully stainless steel enlarged conditioner ensures good cooking effect.
4.Permanent magnet is available.
5.International advance steam fittings and imported pressure reduction valve
6.It is widely used for pelletizing high rank poultry & Livestock products.
Ring die of sawdust compression ratio
♥ Sawdust's raw material : The rosewood floor, composite floor 1:4.5
♥ Sawdust's raw material : Camphor wood, pine, pinus 1: 5.5
♥ Sawdust's raw material : Rubber wood and hard wood 1:5.5
♥ Sawdust's raw material : Larch and spruce 1:6 ~ 1:6. 5
Working Principle: Raw materials with water content no greater than 15% enter into screw feeder through hopper, through adjusting the rotational speed of screw feeder axis to obtain the suitable flow of material, the security magnets remove the magnetic impurity mingling with supplies, then through the enforced feeder, enter the pressing room to pelletize finally.
