rack and pinion for glasshouse ventilation
- 30 Set / Sets per Month
- Shanghai
- T/T
- rack and pinion for greenhosue automatic ventilation system
- multi-span greenhouse rack and pinion equipment
- Automatic venlo greenhouse rack and pinion shading system
- Rack and pinion for wind opening
- greenhouse window opening system rack and pinion
- greenhouse rack and pinion for window opening system
Product Details
Size: | Large | Type: | Other, shading system | Cover Material: | Other, steel |
Model Number: | MP-series | Place of Origin: | Chongqing, China | Brand Name: | Maxpower |
Packaging Details
standard package
Product Description
Specifications
greenhouse ventilation rack and pinion2),High security
3), Self control
4), Running smoothly
Greenhouse Rack & Pinion Ventilation System
Equipment for greenhouse from Maxpower
1, Product instruction
The Greenhouse Rack & Pinion Ventilation System can,
1,Changing the temperature and co2 density of inner greenhouse.
2,Running smoothly with high security, high efficiency and accuracy
3,With self-control function
2, Components and Application
Index | Name | Specification | Unit |
1 | Gear Motor for Ventilation | 380V/750W | set |
2 | Rack for ventilation | pc | |
3 | Pinion for ventilation | pc | |
4 | Sash Bracket | pc | |
5 | Shaft Support | Φ32 Φ42 | pc |
6 | Motor Bracket | T shape | pc |
3.Detail for Gear Motor
Model | Voltage | Power | Output revolution | Output Torque |
SLC-KC550 | 380V | 550W | 2.6r/min | 400N.m |
SLC-KC750 | 380V | 750W | 2.6r/min | 800N.m |
4, Pictures for the components
5,Application
