Powerician 255Wp Poly Solar Panel 0~+3% Power Tolerance
On Grid Solar Panel 255Wp Poly Module for Solar Project OEM Solar for Solar Park
Powerician supply high quality solar panels(solar modules) with compatitive price. Both monocrystalline silicon(mono) and polycrystalline silicon(poly) can be found at Powerician.
OEM service is also provided.
Small quantity order is accepted by Powerician.
We are authorized distributor of solar panles. These panels do not only supplied within the system, but alos supplied as single products.
On Grid Solar Panel 255Wp Poly Module for Solar Project OEM Solar for Solar Park
Features:
- Power tolerance (0~+3%) ensures the high relability of power output
- Drainage holes in frame design, ensures withstanding various weather condition
- High reverse current resistance design.
- TUV certified modules, with high level of wid loads (2400Pa) and snow load(5400Pa)
- Junction box and bypass diodes uarantee the moduls free of overheating and "hot spot effect"
- Product insuranced by world leadign insurance company.
- IEC61215,IEC61730,CE,RoHS certificated
- ISO9001 and ISO14001 certificated factory manufactered
Mechanical Specification
On Grid Solar Panel 255Wp Poly Module for Solar Project OEM Solar for Solar Park
| Cell Type | Poly Crystalline 156x156mm |
| Number of Cells | 60(6x10) |
| Dimensions | 1640Lx990Wx40T mm |
| Weights | 21kg |
| Front Glass | 3.2mm Tempered Low Iron Glass |
| Frame | Clear Anodized Aluminium Alloy |
| Junction Box | IP65 with Bypass Diodes |
| Connector | MC4 compatible |
| Output Cables | TUV, ±Length 900mm, 4.0mm2 |
Electric Parameters
| Max Power at STC(Pmax) | 230W | 235w | 240 | 245W | 250W | 255W | 260W | 265W |
| Short Circuit Current(Isc)-A | 8.60 | 8.43 | 8.57 | 8.63 | 8.71 | 8.80 | 8.89 | 8.94 |
| Open Circuit Voltage(Voc)-V | 36.2 | 35.6 | 37.5 | 36.1 | 36.3 | 36.4 | 36.7 | 37.0 |
| Max Power Current(Impp)-A | 7.90 | 7.88 | 8.00 | 8.05 | 8.17 | 8.30 | 8.42 | 8.5 |
| Max Power Voltage(Vmpp)-V | 29.1 | 29.8 | 30.0 | 30.4 | 30.6 | 30.7 | 30.9 | 31.0 |
| Module Effiency | 14.17% | 14.47% | 14.48% | 15.09% | 15.40% | 15.71% | 16.01% | 16.2% |
| Power Tolerance | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% |
STC-- Irradianc 1000W/m2 Module temperature 25°C AM=1.5
On Grid Solar Panel 255Wp Poly Module for Solar Project OEM Solar for Solar Park
Temperature Characteristics
| Norminal Operation Cell Temperature(NOCT) | 45±2°C |
| Temperature Coefficient of Pmax | -0.44%°C |
| Temperature Coefficient of Voc | -0.34%°C |
| Temperature Coefficient of Isc | 0.06%°C |
On Grid Solar Panel 255Wp Poly Module for Solar Project OEM Solar for Solar Park
System Intergration Parameters
| Max System Voltage | DC 1000V |
| Max Series Fuse | 15A |
| Operation Temperature | -40 to +85°C |
| Number of Bypass Diodes | 3 or 6 |
Mechanical Drawings
On Grid Solar Panel 255Wp Poly Module for Solar Project OEM Solar for Solar Park
Performance Curve
Packing Coniguration
| Container | 20`GP | 40`GP |
| Pieces Per Pallet | 27 | 27 |
| Pallets Per Container | 14 | 28 |
| Pieces Per Container | 356 | 756 |
Each panel in one plastic bag.
27 pcs of panel in 1 carton box
Each carton box fixed on the pallet with belt
Wooden box is offered with extra charge
On Grid Solar Panel 255Wp Poly Module for Solar Project OEM Solar for Solar Park
