Specifications
1 production speed: 350-400pcs/min2 qualification rate : more than 98%
3 sold to Canada Pakistan Malaysia Nigeria Iran
BABY DIAPER MACHINE
1 Technical parameters:
Model SSS-NK400
Designed speed 180 M/Min
Practical speed 350-400 pieces/min
Installed capacity 140KW (380V 50HZ)
Practical capacity 110KW (380V 50HZ) Breaker Capacity: (400A )
Electric wire 3×70 mm2+1×25 mm2+1×16 mm2
Machine size 26.5×6×3 M(L×W×H)
Working space 30.5×10×4M (L×W×H)
Machine weight about 38T
Product size L×W(to be adjusted) S:(380×270)mm M:(450×310)mmL:(520×330)mm XL:(540×340) mm
2 Functions&features
The machine can produce regular type, economic type and high grade type baby diapers
Customer can choose the optional device to produce elastic side tape products
All cutters equip with axis transmission design, can change the products size without changing any
transmission parts on machine
Materials of stereo-protection are complex and molding on machine
Waistband, frontal tape and side tape are cut automatically
Extension of rubber band can be regulated
The quantity of SAP and fluff pulp can be adjusted freely according to the customer’s requirements
Raw materials automatic unwinding system, automatic tension control system, automatic splicing units, automatic rejection units, automatic web guard system.
Frontal tape and side tape out-set from the main machine to make it convenient to change raw material
The machine is attached with fully automatic packing machine (Stacker), make packing simpler and save labor force
Machine equipped with protection door
Touchable Screen: Machine switch on/off, running speed, time, counting pieces, parameter setting, alarm, error display, error enquiry (functions setting appear on screen are different according to different machine type)
3. OUR PROMISE
1, we can customize the production line, as per customers' requirements.
2, our whole set of components are all imported from overseas.
3, within one year, all components are free to replace when wrong since the day of installation.
4, engineers available to service machinery overseas.
5, we can supply raw materials for your production.
4. PICTURES
