Flash Evaporation Cooling System Fine Water Mist Nozzle

Specifications

Mist Fog Nozzle, cooling Nozzle, Ceramic Fog Nozzle
Material: 316ss and ceramic orifice
Orifice: 0.1mm-0.5m
Design Fog System



Features:

    1. Body Materials: 316 stainless steel
    2. Spray Orifice: Ceramic insert
    3. Orifice Dia.: 0.1mm(.004"), 0.15mm(.006"), 0.2mm(.008"), 0.3mm(.012"), 0.4mm(.016") and 0.5mm(0.02")
    4. Spray Patterns: fine fog spray
    5. Spray angles: from 45 to 90 degree
    6. Pressure Range: 20 to 130 bar (0.0125 to 0.24 L/min)

    7. Technical Data:

Part No.	Body Material	Inlet Thread	Orifice Dia.(mm)		Working Pressure		Flow rate		Spray Angle
			mm	in	bar	psi	LPM	GPM
FG010	Brass/SS	10/24-UNC/2A	0.1mm	0.004"	20-70	300-1000	0.013-0.02	0.003-0.005	45-55
FG015	Brass/SS	10/24-UNC/2A	0.15mm	0.006"	10-70	150-1000	0.023-0.05	0.006-0.013	50-65
FG020	Brass/SS	10/24-UNC/2A	0.2mm	0.008"	10-70	150-1000	0.028-0.07	0.007-0.018	55-70
FG030	Brass/SS	10/24-UNC/2A	0.3mm	0.012"	4-70	60-1000	0.045-0.093	0.012-0.026	65-75
FG040	Brass/SS	10/24-UNC/2A	0.4mm	0.016"	4-70	60-1000	0.07-0.150	0.018-0.040	80-85
FG050	Brass/SS	10/24-UNC/2A	0.5mm	0.020"	4-70	60-1000	0.083-0.165	0.021-0.043	80-90

   8. System Kits:

We can also supply the misting system/fogging system kits, such as nozzle quick coupling connector, tee quick coupling, elbow quick coupling, male adpater quick coupling, tube, clamp, end quick coupling, forfex, water filter, ball valve, pump of 2LPM-24LPM etc.

If you are interested in our products, kindly send us your email to get more details. We will do everything possible to please you.

RELAB has a strong ability to quick production and delivery in a short time, we have many customers around the world, because it is possible to accept a small purchase order for your trial.



  10. Application:

Our fog nozzles can be used in fogging system,  when the pressure reaches 80-130bar, it produces very fine fog. For the unique design you can more easier to remove or replace the anti-drip or ceramic sheet.

The Fog Nozzle is an ideal fog maker for misting, cooling and humidifying in outdoor, indoor, garden, piazza, verandah, barn, factory, etc.



Our professional engineer can assist you to design the misting system/fogging system, DIY fogging system will be very easy.
