QBK-40(1 1/2inch) High Viscosity Pneumatic Double Diaphragm Pump Hot
- 500 Set / Sets per Month
- Shanghai or Ningbo
- T/T Credit Card
-
MONO progressive block for prefabried concrete houses
-
MONO progressive block for concrete pump spare parts
-
MONO progressive block for ready mix concrete trucks
-
MONO progressive block for concrete statue molds
-
MONO progressive block for concrete columns mold
-
MONO progressive block for gearbox for concrete mixer
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | DEFU | Model Number: | QBK-40 |
| Theory: | Other, Reciprocating diaphragm deformation caused by volume changes | Structure: | Diaphragm Pump | Usage: | Air Pump |
| Power: | Pneumatic | Standard or Nonstandard: | Standard | Fuel: | Other, compressure air |
| Pressure: | High Pressure | Application: | Other, Corrosive liquid/oil/shampoo etc |
Product Description
Specifications
QBK-40(1 1/2inch) High Viscosity Pneumatic Double Diaphragm Pump1 Size:10-80mm
2 Flow:0-63.6m3/h
3 Head:0-84m
QBK-40(1 1/2inch) High Viscosity Pneumatic Double Diaphragm Pump Hot
Air operated double diaphragm pump
Inlet/outlet | 06-80mm | |
Capacity | 0-63.6m3/h | |
Head | 0-84m | |
Sucktion Lift | 6.4-8m | |
Exit Pressure | 7-8.4 kgf/cm2 | |
Max Grain Dia | 9.4mm | |
Max Air Pressure | 8.4 kgf/cm2 | |
Max Air Consumption | 9.8 m3/min | |
Certification | ISO9001:2008;CE | |
Pump body | Stainless Steel, Cast Iron, Aluminum, Polypropylene, Engineering Plastic, Cast Steel+Teflon Lined, Cast Iron+Rubber Lined; | |
Diaphragm | NBR,Viton,Neoprene,Teflon,EPDM,Santoprene,Hytrel,PVDE etc. | |
Model | Flow (m3/h) | Head (m) | Suction Stroke (m) | Max Particle Dia. (mm) | Max.Air Pressure (kg/cm2) | Max.Air Consumption (m3/min) |
QBK06/10 | 0-1.62 | 0-84 | 6.4 | 1.6 | 7 | 0.14 |
QBK-15 | 0-3.42 | 0-84 | 7.6 | 2.5 | 8.4 | 0.56 |
QBK-25 | 0-9.42 | 0-84 | 8 | 4 | 8.4 | 1.12 |
QBK-40 | 0-21.48 | 0-84 | 8 | 5 | 8.4 | 2.24 |
QBK-50 | 0-35.22 | 0-84 | 8 | 6 | 8.4 | 2.8 |
QBK-80 | 0-63.6 | 0-84 | 8 | 9.4 | 8.4 | 9.8 |
express way etc.Defu Machinery is an Enterprise involved in designing ,developing ,manufacturing and selling water pumps , Including self priming pump ,centrifugal pump ,diaphragm pump , gear pump , diesel engine pump and some others . Relying on the local industrial chain , DEFU has established its production base in Shanghai ,Hubei and Shandong province .
Welcome To Our Factory!
Contact me if u take interest in our pumps.
