Electric Oil Drum Pump/SB Pump
1. Product Introduction:
SB Series Electric Transfer Pump is a kind of barrel pump, it is easy to use and maintenance, and high efficiency. SB Series Electri Transfer Pump can put the tube into the drum to pump liquid. It is widely used to transfer acid, alkali, oil and drink, and some low-viscosity liquid in industry of chemical plant, petrochemical industry, Fine Chemicals, dye chemical, water treatment and food section etc. SB Series Electric Transfer Pump is also an ideal oil transfer tool in oil station, oil tanker, ship, truck etc.
2. Features:
1. It can transport all kinds of oil, corrosion chemical medicine and other liquids
2. It has small size and Light weight
3. Convenient operation maintenance
4. 220V 50HZ 880W drum pump
5. It is an excellent fuel transfer tool
| Working Principle: | Submersible |
| Main applications: | Oil, water, chemical, beverage |
| Max.permissible fluid temperature: | 110°C(230°F) |
| Casing parts material: | S.S, PP, aluminum alloy |
| Maximum viscosity: | 2X103C.S.T |
| Maximum drive rating: | 1.1KW(1.5HP) |
| Maximum caliber: | 50mm(2inch)-In/25mm(1inch)-Out |
| Maximum speed: | 12000r/min |
| Maximum head: | 10m(32.8ft) |
| Flow rate range: |
10-150L/min(2.6-39.6US.GPM) |
| Product Model | Max.Flow( L/min) | Max.Head (M) |
Power (W) |
Speed (r/min) |
Diameter of pump tube (mm) |
Outlet diameter (mm) | Material of pump tube | Material of impeller | N.W |
| SB-1 | 130 | 7.5 | 1100 | 10000 | 50mm | 25 | SS304 | PP | 7.8kg |
| SB-1-2 | 130 | 7.5 | 1100 | 10000 | 50mm | 25 | SS304 | 8kg | |
| SB-1-1 | 110 | 7.5 | 880 | 10000 | 50mm | 25 | SS304 | PP | 7.5kgs |
| SB-1-3 | 110 | 7.5 | 880 | 10000 | 50mm | 25 | SS304 | 7.8kgs | |
| SB-2 | 130 | 7.5 | 1100 | 10000 | 50mm | 25 | AL | PP | 5.5kgs |
| SB-2-1 | 110 | 7.5 | 880 | 10000 | 50mm | 25 | PP | 5.3kgs | |
| SB-3 | 150 | 10 | 880 | 12000 | 50mm | 25 | SS304 | PP | 9kgs |
| SB-3-1 | 150 | 10 | 880 | 12000 | 50mm | 25 | SS304 | 9.5kgs | |
| SB-3-316L (HD-EX2-V+HD-SS316L-1000) | 198 | 12 | 880 | 12000 | 42mm | 25 | SS316L | PVDF/SS316L | 10kgs |
| SB-3-316L-HP (HD-EX2-V+HD-SS316L-1000) | 120 | 30 | 880 | 12000 | 42mm | 25 | SS316L | PVDF/SS316L | 10kgs |
| SB-3-RPP (HD-EX2-V+HD-PPHT-1000) | 198 | 12 | 880 | 12000 | 41mm | 25 | PPHT | PVDF/PP | 8kgs |
| SB-3-RPP-HP (HD-EX2-V+HD-PPHT-1000) | 120 | 30 | 880 | 12000 | 41mm | 25 | PPHT | PVDF/PP | 8kgs |
| SB-4 | 150 | 10m | 880 | 12000 | 50mm | 25 | AL | PP | 5.7kgs |
| SB-5-PP-1 | 20 | 3 | 120 | 5600 | Max.viscosity 150cps | PPHT | 5.1kgs | ||
| SB-5-SS-1 | 20 | 3 | 120 | 5600 | SS304 | 5.8kgs | |||
| SB-6 | 100 | 7 | 550 | 8000 | 41mm | 25 | SS304 | SS304 | 5.7kgs |
| SB-7 | 100 | 7 | 550 | 8000 | 41mm | 25 | SS304 | PP | 5.5kgs |
| SB-8 | 100 | 7 | 550 | 8000 | 41mm | 25 | AL | PP | 3.8kgs |
| SB-550W+HD-SS304-1000HP | 70 | 22 | 550 | 8000 | 42mm | 25 | SS316L | PVDF/SS | 6kgs |
| SB-550W+HD-AL-1000HP | 70 | 22 | 550 | 8000 | 41mm | 25 | AL | PVDF/PP | 4kgs |
| SB-550W+HD-PPHT-1000HP | 70 | 22 | 550 | 8000 | 41mm | 25 | PPHT | PVDF/PP | 4kgs |
| SB-550W+HD-PVDF-1000HP | 70 | 22 | 550 | 8000 | 41mm | 25 | PVDF | PVDF | 4kgs |
| JK-3B | 40 | 3 | 120 | 2850 | 55mm | 20 | AL | PP | 3kgs |
| JK-3BG | 40-60 | 6 | 180 | 2850 | 55mm | 20 | PP | 6kgs | |
| JK-3BP | 40 | 3 | 120 | 2850 | 55mm | 20 | SS304 | PP | 6kgs |
| JK-3BPG | 40-60 | 6 | 180 | 2850 | 55mm | 20 | PP | 7kgs | |
| YBYB-40 | 40 | 3 | 120 | 2850 | 55mm | 20 | AL | PP | 7kgs |
| YBYB-40G | 40-60 | 6 | 180 | 2850 | 55mm | 20 | PP | 7.5kgs | |
| YBYB-40P | 40 | 3 | 120 | 2850 | 55mm | 20 | SS304 | PP | 8kgs |
| YBYB-40PG | 40-60 | 6 | 180 | 2850 | 55mm | 20 | PP | 9.5kgs | |
1. Q: Whats the MOQ ?
A: 1 set for regular product ,the special one we need to discuss.
2. Q : What're your payments ?
A: For small order valve < 4000USD, our customer chose 100% T/T.
For order valve >4000USD, we can accept 30 % T/T inadvance , 70 % should be paid before shipping.
3 . Q : How long is the deliver time ?
A : For the order in stock ,we will deliver goods at once against payment.
For the orders out of stock , the products time is 7 days for bare pump, 25days for electric pump set or diesel engine pump set , the deliver time is base on the shipping date and your order by sea.
4. Q: What about the package ?
A : Standard export Plywood case or carton
5.Q : How is the pump delivered to us ?
A : For small order will be delivered by internation express ,like DHL,TNT ,FEDEX,UPS.
For large order ,it will be delivered by air ,sea ,vehicle or multi-modal transport.
6. Q : How long is the warranty ?
A: According to the internation standards , pump in standard operation is 1 year ,3 monthes for spare parts.
DEFU Machinery is an enterprise involved in designing, developing, manufacturing and selling water pumps. Relying on the local industrial chain, DEFU has established its production base in Shanghai, Hubei and Shandong province.
Our main product:
self priming pump, double suction pump, diaphragm pump, diesel engine pump, multistage pump, gear pump and some others.
Lena Chen-Sales Manager
Mobile/Whatsapp/wechat/line:+86 15067784809
Skype: defucc1
Tel:+86-577-86553155
Fax: +86-577-86553150
Trademanager: cn1500363297
E-mail:sales1 @
sale1 @defucc.cm
ylpump1 @defucc.com
lena @ylpumpm.com
Or Click ↓ " Send " ↓ with your requirement.
