Double Layer Rotary (Static)sterilizing kettle
- 1000 Set / Sets per Month
- any china port
- T/T Credit Card PayPal
- Professional pipe hydraulic pressure test equipment machine with automatic print test reports
- manual and automatic type stainless steel centrifugal milk cream separator
- manual and automatic type stainless steel milk cream separator machine
- semi-automatic centrifugal Milk/dairy cream separator
- automatic centrifugal Milk/dairy fat separator
- automatic Milk/dairy Cream separator
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | REALLY |
Model Number: | RL-700 | Usage: | Canned Food | Type: | Ultra High Temperature |
Voltage: | 380V/220V | Power(W): | 30KW | Weight: | 800kg |
Dimension(L*W*H): | 1500*900*1900mm | Certification: | CE ISO | Warranty: | 12 Months |
After-sales Service Provided: | Overseas third-party support available |
Product Description
Double Layer Rotary (Static)sterilizing kettle |
1 introduction of the food Sterilization pot |
Full-auto two-layer immerse autoclave has top& bottom pots. Top one is to save hot water and bottom one for sterilization. After packed food entered the sterilization pot the pre-heated sterilization water from the top pot comes into the bottom sterilization pot and immerse all the food in the pot like people bathing in pool. Then circulating pump force the high temperature water in the pot to recycle regularly. During the running steam continually heats them to the designed temperature to proceed to packed food sterilization purpose. The high temperature water recycles to the top pot after sterilization finished and the coolant water input directly to the bottom pot from outside to finish cooling process. This device process sterilization with recycle of hot water between top & bottom pot. Sterilization technique and process are full automatically controlled to save space, energy& sterilization time and increase output |
2 the Technical parameter of the food sterilization pot |
Model | Inner diameter | Canister length | Total length | capacity | Volume |
700 | 0.7 | 1.2 | 1.7 | 120-150kg | 0.7 |
800 | 0.8 | 1.5 | 2.3 | 200-250kg | 1.1 |
900 | 0.9 | 1.8 | 2.5 | 300-350kg | 1.3 |
1000 | 1 | 2.2 | 3.0 | 500-550kg | 2.1 |
1200 | 1.2 | 3 | 3.8 | 800-1000kg | 4.0 |
Model | equipment |
700(gas or electric,30kw) | Equip with food dishes 3pieces,tray 1piece,cart 1uint |
800(gas or electric,36kw) | Equip with food dishes 6 pieces,tray 2 piece,cart 2uint |
900(gas or electric,45kw) | Equip with food dishes 8 pieces,tray 2 piece,cart 2 uint |
1000(gas or electric,60kw) | Equip with food dishes 10 pieces,tray 2 piece,cart 2 uint |
1200(gas or electric,90kw) | Equip with food dishes 15 pieces,tray 3 piece,cart 3 uint |
design temperature | 145° |
test pressure | 0.44Mpa |
Design pressure | 0.35Mpa |
3 specification of the food sterilization pot |
1. | It is heated directly but it is cooled indirectly. The cooling water and sterilizing water are not mixed together, avoiding the secondary pollution. |
2. | It does not need water sterilizing chemicals and the high temperature can contribute to the sterilization in a short time. |
3. | A small quantity of sterilizing water can circulate quickly to reach the expected sterilizing temperature. |
4. | Multiple-step temperature raise and down can keep the color and flavor of food production. |
5. | Low noise, energy saving, water saving and environment protection. |
6. | It can save space and labor. It is operated easily. |
7. | Precise pressure control system can ensure food package won’t change in cooling period, especially inflated packaged food. |
4 RFQ |
Q1 | what are the payment iterms? |
A | we usually accept payment byT/T,L/C,Western Union or Escrow |
Q2 | can any of the products be custome imprinted? |
A | if you need to print your compay logo on the products and that is available to be custom.orif you hav eyour own designed idea and that will be our honor to customize for you. |
Q3 | this is my first time to import,how can i trust your company and ensure to get the goods if i order from you? |
A | we are alibaba legitimate certification company (VIP),andwe support payment terms like L/C,Escrow,to ensure your safty. |
Q4 | how to ensure that I receved the machine undamaged? |
A | at first,our package is standard for shipping,before packing,we wil confirm product undamaged,otherwise,please contact within 2 days,Becuse we've bought insurance for you,we or shipping company will be responsible! |
Q5 | where will the orders be shipped from? |
A | it will ship from the main ports China,and we've will fins the shipping company which will offer the best freight for you,But is you have a preferred carrir,that will be more helpful for us. |
Q6 | b sea,by air,or via DHL,UPS,TT,FEDEX,EMS,etc. |
