rotary drum dryer for sale
Rotary drum dryer for sale introduction:
Rotary drum dryer for sale is mainly used to drying wet materials in building constuciton, metallurgy, chemica industries, ad it can dry various materials with strong adaptability. Besides, it is common drying device in cement plant with simpel and reliable operation.
In our compamny, this series applies the new type scatter palte device: it can guide direciton, flow on an average and scatter the materiala andso on. And it can make the materail in the thin, average and complete condition. Contact the heat airflow compeltely and use the heat energy fully. Moreveer, it adopts resonable operational parameter, and compared with generatl drier, it reduce the caol and power consumtion above 10-15% and increase the output above 10-15%. it is widely used in cement and mining industries and biomass lies too.
Rotary drum dryer machien is mainlyu to dry biomass fertlizer power materaials, at max feed 15mm dimension materails changeable spped rotary drum, which can dry high humidity materials, such as to dry biomass from sawdust straw stalk etc for factory use.
Rotary drum dryer machine drum RPM can be controlled according to raw materails humidity if humidity is large then can control feeding speed and drum RPM lower to make long drying time. The longer drum ensure high heat use efficiency.
Rotary drum dryer machine has two ways to discharge materials, one is to outlet from rotary drum bottom, it is mainly fit for larege weight ratio materials, the other is to outlet materails from cyclone bottom, which mainly fits for light ratio materials. On one hand with hig drying efficieceny, on the other hand to clean dust.
Rotary drum dryer machine features and benefits:
1 Reasonable design of raising board and angle ensure the materails well distributed and drye with less times itt has reliable operation and high energy utiliztion rato, simpel maintennace.
2 Rotary drum dryer adopt an adjustable center tug strutctue, the good cooperation of the tug and the rolling ring reduce the attention and energy consumptption.
3Speical structure of the dam wheel decrease the rorizeontal trhuest, when the machien working in inclination station, it has strong ability of anti overloading, steady oiperation and high realiability.
4 High tempreature resisitance, it can use the high temerapture to dry the materials quickly
5 Large capacity, few feul consumption , low drying cost.
Rotary drum dryer machine parameter:
Model |
Power (kw) |
Steam Evaporation capacity (ton) |
DZLP0.8*6*1 |
4+3 |
0.1-0.2 |
DZLP0.8*12*1 |
4+5.5 |
0.2-0.3 |
DZLP01*6*1 |
4+7.5 |
0.2-0.3 |
DZLP01*12*1 |
5.5+7.5 |
0.4-0.5 |
DZLP1.2*12*1 |
5.5+7.5 |
0.4-0.6 |
DZLP1.4*12*1 |
5.5+11+7.5+3 |
0.6-0.8 |
DZLP1.5*12*1 |
5.5+15+7.5+4 |
0.8 |
DZLP1.6*12*1 |
5.5+18.5+7.5+4 |
0.8-1 |
DZLP1.6*24*1 |
7.5+22+15+5.5 |
1.1-1.2 |
DZLP1.8*12*1 |
7.5+18.5+11+4 |
0.8 |
DZLP1.8*12*3 |
11+30+5.5 |
1 |
DZLP1.8*24*1 |
11+30+4 |
1 |
DZLP2*12*1 |
7.5+22+11 |
1.2 |
DZLP2*12*3 |
11+45+5.5 |
1.5 |
DZLP2*24*1 |
7.5+37 |
1.2 |
DZLP2.2*12*1 |
7.5+22+4 |
1.2 |
DZLP2.2*12*3 |
11+45 |
1.5 |
DZLP2.2*24*1 |
7.5+37 |
1.8 |
DZLP2.5*12*1 |
15+22+4 |
1.5 |
DZLP2.5*12*3 |
18.5+45 |
1.8 |
DZLP2.5*24*1 |
15+37 |
1.8 |
DZLP2.8*12*1 |
18.5+30+4 |
1.8 |
DZLP.8*12*3 |
22+55 |
1.8 |
DZLP2.8*24*1 |
22+45 |
2.4 |
DZLP3*12*1 |
22+45+4 |
2.5 |
DZLP3*12*3 |
30+55 |
2.5 |
DZLP3*24*1 |
22+45 |
3 |
DZLP3.5*24*1 |
30+45+5.5 |
3.6 |
DZLP3.5*12*3 |
75+45 |
3.8 |
DZLP3.5*24*1 |
22+45 |
3 |
About Us:
As a professional manufacturer of biomass rotary dryer with CE & ISO certificate in China, we can take responsibility to our every client very seriously.
The rotary dryers use for drying many kinds of materials and finished products, such as the crop straw powders, sawdusts, small wood shavings/chips, animal waste, household waste and so on. The dryers generally applied to the farm straw processing plant, wood working factory, organic fertilizer factory and Chinese medicine factory.
The rotary dryers adopt air inhale device to inhale the hot air from air-heating furnace to the inner of dryer to complete heating change with wet material. According to the different character of materials, we use different type lifting plate and Anti-sticking measures.
There are multi angle lifting style lifting plate inside of rotary dryer; during drying, the lifting plate will raise the material evenly, which can ensure the material complete heating change with the hot air enough and also ensure the drying efficiency is good.
Our promise to you……
I promise to provide a high quality product at a fair price that will last for years and years, shipped as quickly as possible along with professional engineers support you require to get you up and running.
You can call me anytime on trademanager. I’m always working and I never sleep! (Ok, maybe sometimes.)
All the parts of products are rechecked before transportation, therefore the clients will receive the best quality products..
Free consulting service, please contact us when you have any questions about biomass pellet machinery.
1 Year Warranty on all parts.
Why buy from us
Chang Sheng is one of the largest manufacturer of pellet stove, pellet boiler, and pellet making machine in China. That is why we can offer you brand new products at extremely low prices.
We are the experts of biomass fuel machinery field, there is a professional team of designing and manufacturing in our factory. All the material and process are controlled strictly, that our products have a unique cost performance.
Shipping cost
Please Message or Call us. If You Have Questions About The Shipping Cost, Depending On Your Location, It May Be Cheaper!! When Contacting Us Please Provide Your Zip Code.
Packing
The kind of packing will be decided by our clients, or you can leave it to us. Whatever which one is used, all the good will be packed carefully by our professional workers to ensure the safety of your shipment.
After –sales
Quality is the soul of our factory, we have design departments, equipment installation department and after-sales department which helps our clients all over the world. They gain huge reputation for our company.
Our after-sales service includes: equipment debugging and installation,Product guidance, spare parts delivery, shipment follow up. If you have any question please contact us, We will do our best to accomplish your requirement on time.
