Liquid Nitrogen Container

Name: Liquid Nitrogen Container
Brand: ilonger
SKU: 139280181

US$ 110 - 1,250 MOQ: 1 Piece

Key Specifications

Brand Name:

ilonger

Model Number:

YDH-3 Liquid nitrogen storage container for semen

Shenzhen Longer Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Brand Name ilonger

Model Number YDH-3 Liquid nitrogen storage container for semen

Specifications

Liquid nitrogen container for storage semen
High-strength aluminum alloy structure
Lockable cover,protecting biologicalsample

Liquid nitrogen container for storage semen

1.YDH-8-80,YDH-3 Liquid nitrogen storage container for semen

Liquid nitrogen container for semen is liquid nitrogen adsorber in the inner vessel of the series products.

The adsorber absorbs and stores liquid nitrogen inside,and even if the container is turned over during

transportation,liquid nitrogen never spills out.

It is less static evaporation loss mass of liquid nitrogen and safter usage,especially suitable for air transportation.

2. Specifications of Liquid nitrogen storage container for semen

Mode	Unit	YDF-3	YDH-8-80
Capacity	L	3.5	8.0
Empty Weight	Kg	5.2	8.9
Caliber	mm	50	80
Outer Diameter	mm	224	303
Height	mm	535	610
Static Evaporation Loss Mass	L/d	0.14	0.22
Static Holding Time	d	25	36
Number of Canisters	n	1	1
Canister Outer Diameter	mm	38	70
Straw Holding Capacity	0.25ml	472	1780
Straw Holding Capacity	0.5ml	214	820
Number of Canes	n	4	15
Number of Vals	n	20	75

3.Secure,energy saving,lower cost of total ownership:

1.Less NER means secure,longer top up interval,less risky of losing bio-specimen.

2.Less NER means energy saving,green

3.Less NER means lower cost of total ownership

4.Parts Configurable:

1.Customer has freedom to configure parts,and procure each and every possible configurable.

2.Abundant parts including LN2 pumps,LN2 measure rulers,canisters,racks...

5.Perfect production enviroment:

Our company has advanced machinery,accurate inspection and test instrument and experienced research engineer.

Our company has modern and beautifu workshop.

Our company insisted in strict quality control during fabricating,every fabricating step has inspecting process.

6.Main Features:

High-strength aluminum alloy structure;
Protecting jacket,portable and preventing collision;
Lockable cover,protecting biological samples stored;
Multi-layer thermal isolation desigh,more than five-year vacuum quality guarantee
