Product introduction
agricultural irrigation diesel water pump diesel engine water pump 3 inch diesel water pump
| Model | DP20 | DP30 | DP40 | |
| WATER PUMP | Suction, discharge port diameter [mm(in)] | 50(2") | 80(3") | 100(4") |
| Max Total head lift (m) | 26 | 25 | 31 | |
| Cont. Total Head | 15 | 13 | 16 | |
| Max suction head (m) | ||||
| 8 | 8 | 8 | ||
| Discharge capacity (m3/hr) | 22 | 30 | 40 | |
| ENGINE | Engine model | 170F(E) | 178F(E) | 186F(E) |
| Max output(hp/rpm) | 3.7/3000 | 5.5/3000 | 8.2/3000 | |
| Cont. Output | 3.5/3000 | 5/3000 | 7.8/3000 | |
| Speed (rpm) | ||||
| 3000/3600 | 3000/3600 | 3000/3600 | ||
| Type | ||||
| Single-cylinder,vertical,4-stroke air-cooled diesel engine | ||||
| Recoil or Electric | ||||
| Displacement (cc) | 211 | 296 | 406 | |
| Bore × stroke (mm) | 70x55 | 78x62 | 80x70 | |
| Starting system | ||||
| Recoil or Electric | ||||
| Fuel tank capacity (L) | 2.5 | 3.5 | 5.5 | |
| STANDARD FEATURES | Oil alert | yes | yes | yes |
| Connecter of infall, Connector of outfall | yes | yes | yes | |
| Fitter | yes | yes | yes | |
| Seal ring | yes | yes | yes | |
| Hoop | yes | yes | yes | |
| OPTIONAL FEATURES | Luxury big fuel tank | optional | optional | optional |
| DIMENSIONS | Dimension (LxWxH)(mm) | 505x425x540 | 585x470x575 | 670x490x625 |
How to order?
Please send us your purchase order by E-mail or Fax, or you can contact us by trade manager
skype,QQ or take an telephone call to us.
We need to know the following information for your order:
1) Product information: material, sizes, Application, Price Item, Destination Port
2) Delivery time required.
3) Shipping information: Company name, Address, Phone number, Destination seaport/airport.
MOQ
1set can be acceptable for trail order.
Over 3sets can have wholesale price.
Welcome to join us as our sales agent in your market.
OEM and ODM
changing on design , color ,: acceptable(welcome)
develop on artwork and sketch : acceptable
Quality Control
Third party inspection : acceptable
1 year guarantee for quality problems
