Product Details
| Condition: | New | Type: | Core Drilling Rig | Power Type: | Diesel |
| Place of Origin: | Henan, China | Brand Name: | Lance | Model Number: | LJ130 |
| Usage: | Water Well | Voltage: | 220v/380v | Power(W): | 1000kw |
| Dimension(L*W*H): | 5700*2300*2700mm | Weight: | 560kg | Certification: | CE |
| Warranty: | 2 years | After-sales Service Provided: | Overseas third-party support available |
Product Description
portable diamond core drill rig for water well
Applications:
Geological general investigation and exploration, road and tall building groundsill exploration, kinds of hole in concrete structure, river levees, subgrade grouting hole drilling and direct grouting, civil water wells and geothermal air conditioner, etc.
Parameters:
Unity machine parameter | |
Drilling depth | 130m |
Max. open hole caliber | 220mm |
End hole caliber | 75mm |
Drill pipe caliber | 50mm |
Drilling angle | 90°~75° |
Drill weight | 560Kgs |
Spindle | |
Spindle speed: | 142,285,570r/min |
Spindle stroke: | 450mm |
Hoist | |
Max. lifting capacity: | 1600Kgs |
Single line lifting speed: | 0.41,0.82,1.64m/s |
Reel caliber: | 140mm |
Tightrope caliber: | 13mm |
Tightrope size: | 27mm |
Mud pump | |
Type: | Horizontal single-urn double action |
Flow Diesel engine/Electric motor: | 95/97L/min |
Max. pressure: | 1.2Mpa |
Work pressure: | 0.7Mpa |
Water inlet diameter: | 30mm |
Water outlet diameter: | 20mm |
Triangle conveyer belt: | B1575mm |
Equipment photos:
Working field:
