Thawing Machine
Low Temperature&High Humidity Air Defrosting Equipment
Key words: Thawing Machine/ Defrosting machine/ Air Defrosting
Our technical theory is on the basis of using low temperature and high humidity air to blow the surface of frozen products recycling and equally to thaw the frozen products.At the same time,this machine can automatic use PLC to control the temperature and time by stage .
Main Features:
1. High quality of Thawing;
2. Low weight-less rate of the products;
3. Simple operation and strong applicability;
4. Good humidifying device;
5. Hygienic environment;
6. Special stainless cargo vehicles and hydraulic lift platform;
7. Designing according to customers;
Wall Panel:
1.The machine using 100% polyurethane panel;
2.Sides materials: Color steel plate, Stainless steel plate;
3.Specification(Thickness): 50mm, 75mm, 100mm, 120mm, 150mm, 175mm, 200mm, 250mm;
4.Way of Splicing: The convex groove form,Eccentric hook lock box, Sealing material sealing gap;
5.Size: Width 960mm; Any long less than 1200mm;
6.Features of the panels:
Advanced technology;
Good form;
Good heat preservation performance;
Good heat insulation performance;
High strength of the retaining structure with boards;
Scientific design, simple and practical;
Many specifications to meet the need of the various places and
engineering;
DOORS:
1.Sides: according to customers;
2.Materials: polyurethane foaming;
3.Types: sliding doors or swing doors;
4.Motivations: manual doors or electric doors;
Heated & humidification system
Method 1: water steam : The heat conduction through the conduit into inner thawed room,and water steam completed by reduced pressure and steam atomization of double line.
Method 2: One set Italy humidification pump. keep thawing room environment humidity. Winds circulating blows evenly through the frequency wind blows between thawing temperature and humidity.
Refrigeration system
Freon refrigeration cooling stainless steel pipe and copper pipe, cooling pipe insulation adopted sleeves approach to ensure uniform, seamless and insulation effect;
Storage temperature setting range 20 ℃ ~ -0 ℃, evaporation temperature -10 ℃. Condensing temperature 38 ℃, cooling capacity 4.8KW;
Electrical Control System
Transducer parameter settings are according to temperature of center,surface and interior, inside humidity sensor signal;
Technical Standard
After defrosting ,the effects of frozen products keep balance,no oxidization and gray line;
After defrosting,muscular tissue is full luster and elastic;
After defrosting,the lost rate of protein juice is less 1%;
After defrosting,the temperature in the center could be settled at -2±1℃and Particular case is particular setting;
Defrosting type can be settled in several stages and control the process accurately ,time controlled at 10-14H according to the different situation;
Manufacture & Advantages
Advanced technology: German technology, combined with years of production experience,also developing new and improved equipment now. Unique air distribution way and air volume at different thaw periods, with a sub-component of air, and then a more detailed, uniform and accurate air circulation to ensure the best product thawing effect.
Material guarantee: materials comply with food hygiene requirements of 304 stainless steel plate and pipe, (wall panels, air board, corrugated ceiling panels, beams, columns, etc., see the thawing machine parts parameters and price), in order to meet the hygiene needs, structural strength and service life.
Thaw technique is to use low temperature and high humidity of circulating air blowing, make the product surface form a uniform air distribution, PLC automatic segmentation by controlling temperature and time to achieve product thaw. Low humidity thawing equipment not only save costs, but more important is to maintain freshness of original organoleptic characteristics,fully meet the market fresh sailing after thawing.
After-sale Guarantee
we reply on the principle“quality priority,customer supreme,reputation first,honest basis” to offer my products and service for customers:
We can offer the whole demonstration documents,including instructions, Installation, service manual and quality certificate;
We are responsible for installing and debugging all equipment. All parts are supplied by us.Our warranty time is 12month and on-site maintenance for life;
We offer the operation, maintenance and other service for our buyer’s work-staff according to the situation ,e.g time,place,staff and it’s free of charge;
We will offer the quick,in time,excellent after-sale service for the products we sold and we have enough storage to ensure our customers to use;
We will make some inspection ,adjusting and lubricating for free in guarantee period;
We can offer the excellent after-sale service and tech support.All products we offered are made according to the national standard and procedure;
Products sold are according to the existing relevant provisions of "Three Guarantees", the warranty period according to the current national regulations,except damage caused by human factors, all free maintenance;
Once equipment failure during use, after receiving user notification, we will respond immediately and send professional maintenance personnel to site within 24 hours, when arrived at the scene, trouble will be cleared in the shortest time , ensure common work, does not affect the owners to use;
As exceed the warranty period,if equipment failure, company also provide free repair services,but charge for replacement parts. When necessary, we will provide some more concessions, better services;
If the customer urgently needed due to the production, our company will arrange for the production first time to meet customer production demand;
Shandong Huayu Machinery Equipment CO., Ltd
Main products:
Shandong Huayu Machinery Equipment CO., Ltd, located in Boxing with convenient transportation access, is a modern, professional, international and large-scale manufacturer and exporter.
And we have three professional companies to produce slaughtering equipment, cold storage room and other stainless steal workshop products so that we can provide a total service according to your demand.
High Quality:
All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world. Our well-equipped facilities and excellent quality control throughout all stages of production make us to guarantee total satisfaction of the customers. Besides, we have received ISO 9001:2008, CE, HALAL.
Good Oversea Service:
As a result of our high quality products and oversea customer service with a strong engineers and technician team, we have gained a global sales network reaching America, France, Australia, Egypt, Cambodia, Vietnam and 20 other countries and regions.
Contact:
If you are interested in any of our products, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
Mr Walon Wang
Sales Representative
HUAYU MACHINERY EQUIPMENT Co., Ltd.
Mobile:+86 180 0638 5152
QQ: 416936251
Web:http://www.huayuchina.com
