Help CenterSingflo 12v dc Electric Commercial Hydraulic Gear Pump
Related Products
Specifications
12v dc electric commercial hydraulic gear pump12V,12LPM,10A
Self Priming:3m
Bronze body and stainless steel shaft
CE app
Singflo 12v dc electric commercial hydraulic gear pump
Application:
Diesel:Lubricant;Oil, Fuel Viscous liquids
Be able to use for water and machinery fuel9except gasoline)
Specifications:
| Body Materials | Bronze |
| Impeller | Neoprene compound |
| Seal | Lip Type |
| Port(s) | 3/8''Female Thread,1/2''Barbed Fittings Included |
| Voltage | 12V/24 dc |
| Amp Draw | Max.10.0(amp) |
| Fuse Size | 15.0(amp) |
| Motor Type | Permanent Magnet Type Fully Enclosed Stainless Steel Shaft Ball TypeShaft Bearing Reversible |
| Self-priming | 3.0m vertical lift |
| Pressure | Can generate pressures up to 2bar(30psi) |
| Liquids | Lubricants and visous liquids |
Technical data
| Model | Volt | Flow (lpm/gpm) |
Max.Lift (m) |
Amp Draw (A) |
Max draw (A) |
Packing Size (mm) |
N.W./G.W. (kgs) |
| GP-001 | 12 | 12.0/3.2 | 3 | 7 | 10 | 215*135*110 | 2.48/2.68 |
| GP-002 | 12 | 30.0/8.0 | 3 | 8 | 10 | 215*135*110 | 2.38/2.58 |
Photos of Gear Pumps
workshop:
Certificate:
Q: What's your main products of your company?
A: We specialized in all kinds of water pump(drinking water pump,micro gear pump,high performance diaphragm pump,Marine pump,RV pump )for over 10 years with excellent quality and competitive
Q:How can I choose the most suitable pump?
A: Please tell me your detailed flow rate, voltage, application and so on, then I will match the most appropriate pump for you, or you can choose the exact model in the product manual.If you don’t know the details for the pump, tell us the usage, must suitable model will be recommended.
Q: What's your payment way?
A: Usually we accept T/T ,Western Union or PayPal.
Q: What's your delivery time?
A. 1.The stock samples can be sent to you within 3-5days by international express after received
2.The batch order can be shipped to you in about 10-15days after order confirmation (by air or by sea)
Q: How long is your pump lifetime?
A: Pump lifetime mainly depends on motor lifetime,we have DC brush, brushless, coreless brushless motor For your choice, the pump warranty is 12 months.we can supply 1% spare parts for after service.
