singflo water digital flow meter/gas turbine flow meter/flow meter

packaged according to export standard

Specifications

singflo water digital flow meter
1.Flow meter can be used with water,chemical liquid Urea,
2.can be mounted on pump or nozzle

singflo water digital flow meter/gas turbine flow meter/flow meter



The control panel of K 24 Flow meter adopts the concept of modular design, with features of complete function, simple construction, easy operation, etc.



Application:

Widely used in Compatible with DEF (Diesel Exhaust Fluid), Beer, Urea. water, Chemical liquid, Diesel. Petroleum, Chemistry, Medicine, Traffic, Food ,Commercial industry,etc.



Technical data:

Medium	Diesel, urea, kerosene,chemicals, gasoline
outlet&inlet size	1"
measuring accuracy	±1%
repeatability	±0.5%
Max working pressure	20BAR
working voltage	2.3-3.3V
standby time	2 years
flow-rate range	10-120L/MIN
single count	0.00-999.9
total count	0.00-999999.9
measurement unit	L, GAL,PTS,QTS
single measurement reset	RESET



Female thread:





Male thread:





It's available with pulse output / pulser signal out (pulse output line is 0.8m/pc)



1pc/color box, 50pcs/ctn

N.W.:14kgs  G.W.:16kgs



Q: What's your main products of your company?
A: We specialized in all kinds of water pump(drinking water pump,micro gear pump,high performance diaphragm pump,Marine pump,RV pump )for over 10 years with excellent quality and competitive
Q:How can I choose the most suitable pump?
A: Please tell me your detailed flow rate, voltage, application and so on, then I will match the most appropriate pump for you, or you can choose the exact model in the product manual.If you don’t know the details for the pump, tell us the usage, must suitable model will be recommended.

Q: What's your payment way?
A: Usually we accept T/T ,Western Union or PayPal.
Q: What's your delivery time?
A. 1.The stock samples can be sent to you within 3-5days by international express after received
   2.The batch order can be shipped to you in about 10-15days after order confirmation (by air or by sea)
Q: How long is your pump lifetime?
A: Pump lifetime mainly depends on motor lifetime,we have DC brush, brushless, coreless brushless motor For your choice, the pump warranty is 12 months.we can supply 1% spare parts for after service.
