Singflo 12V&24v DC Diaphragm Pump/fuel Pump Diaphragm Material/pump Fuel.

Name: Singflo 12V&24v DC Diaphragm Pump/fuel Pump Diaphragm Material/pump Fuel.
Brand: SINGFLO
SKU: 139203271
Availability: InStock

US$ 80 - 100 MOQ: 10 Sets

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

SINGFLO

Model Number:

HV-30

Xiamen Youme Electric Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

china port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name SINGFLO

Model Number HV-30

Theory Reciprocating Pump

Structure Diaphragm Pump

Usage Water

Power Electric

Standard or Nonstandard Standard

Fuel Other, electric

Pressure Low Pressure

Application Other, fuel pump diaphragm material

Singflo 12V&24v DC diaphragm pump/fuel pump diaphragm material/pump fuel.

Product Description

Application.

Ideal for unloading for chemical liquid transfer,Totes or Drums of adblue, Detergents,Soaps,Acids and Alkalis.

Features.

* Permanent magnet and continuous duty

*Built-in pressure switch automatically stats and stops pump when faucets is opened and closed

*Self-priming so pump can be locate above water tank

*Runs dry for extended periods of time without damage

*Hold excellent motor keep stable temperature of pump

Specification.

Technical Data:

Model	Volts	Open Flow	Pressure	Amps	Speed	N.W / G.W
Model	DC /AC	LPM	Shut Off	(A)	(RPM)	(KGS)
HV-30A	12 VDC	30-35	40 psi (2.8 bar)	15	2800	5 /5.5
HV-30B	24 VDC	30-35	40 psi (2.8 bar)	7.5	2800	5/5.5
HV-30S	115 VAC	30	25 psi (1.7bar)	4	3400	6 / 6.5
HV-30M	230 VAC	30	25 psi (1.7bar)	1.5	2900	6 / 6.5
HV-40S	115 VAC	40	25 psi (1.7bar)	4.2	3400	6 / 6.5
HV-40M	230 VAC	40	25 psi (1.7bar)	1.8	2900	6 / 6.5
HV-50S	115 VAC	50	25 psi (1.7bar)	4.5	3400	6 / 6.5
HV-50M	230 VAC	50	25 psi(1.7bar)	2	2900	6 / 6.5
