Home > Products > Adblue system&pump > Singflo 35L/min-12V fuel and chemical dispenser pump/ Urea automatic chemical pump from China
Singflo 35L/min-12V fuel and chemical dispenser pump/ Urea automatic chemical pump from China
- 10000 Set / Sets per Month
- FOB China Port
- T/T Credit Card PayPal
-
Singflo 50L/min-115V Urea electrical diaphragm pumps/Adblue Pump For Ibc System
-
Singflo 220V AC high flow urea pump acid transfer pump
-
Singflo 220v ac adblue chemical resistant pump with pressure switch
-
Singflo HV-40M 25psi high flow work continuous adblue pump/DEF tote dispenser kit
-
Singflo 220V 50LPM adblue urea pump with EU plug
-
Singflo 220v ac adblue chemical circulating pump with pressure switch
Product Details
| Place of Origin: | Fujian, China | Brand Name: | SINGFLO | Model Number: | HV-30 |
| Theory: | Reciprocating Pump | Structure: | Diaphragm Pump | Usage: | Other, Adblue,area |
| Power: | Other, Electric,ON/OFF SWITCH | Standard or Nonstandard: | Standard | Fuel: | Other, Electric |
| Pressure: | High Pressure | Application: | Other, chemical pumps for IBC system |
Packaging Details
with strong seaworthy carton.
Product Description
Singflo 35L/min-12V fuel and chemical dispenser pump/ Urea automatic chemical pump from China
Features:
Adblue pump for IBC System,DEF pump
1.Continuous working
2.with low temperature
3.Long serivce life,
Permanent magnet and continuous duty
Built-in pressure switch automatically starts and stops
Pump when faucets is opened and closed
Self-priming so pump can be located above water tank
Runs dry for extended periods of time without damage
Hold excellent motor keep stable temperature of pump body
Specification:
PUMP Design: 5 chamber diaphragm
Motor Design: Permanent magnet DC/AC
Voltages: 12, 24VDC,115/230VAC
Diaphragm: Viton
Check valves: Viton
Max. Flow Rate: 30~50LPM
Max. Pressure: 40PSI (2.75BAR)
Liquid Temp: 40°F (5°C)MIN; 140°F (60°C)MAX
Duty cycle: Continuous work with self-ventilated
Weight: 5.5KG for DC pump 6.5KG for AC pump
Adblue pumps techniocal data:
Model | Volts | Open Flow | Pressure | Amps | Speed | N.W / G.W |
DC /AC | LPM | Shut Off | (A) | (RPM) | (KGS) | |
HV-30A | 12 VDC | 30-35 | 40 psi (2.8 bar) | 15 | 2800 | 5 /5.5 |
HV-30B | 24 VDC | 30-35 | 40 psi (2.8 bar) | 7.5 | 2800 | 5/5.5 |
HV-30S | 115 VAC | 30 | 40 psi (2.8bar) | 4 | 3400 | 6 / 6.5 |
HV-30M | 230 VAC | 30 | 40 psi (2.8bar) | 1.5 | 2900 | 6 / 6.5 |
HV-40S | 115 VAC | 40 | 40 psi (2.8bar) | 4.2 | 3400 | 6 / 6.5 |
HV-40M | 230 VAC | 40 | 40 psi (2.8bar) | 1.8 | 2900 | 6 / 6.5 |
HV-50S | 115 VAC | 50 | 40 psi (2.8bar) | 4.5 | 3400 | 6 / 6.5 |
HV-50M | 230 VAC | 50 | 40 psi(2.8bar) | 2 | 2900 | 6 / 6.5 |
Adblue pumps DC mounting:
The HV Series pumps are self-priming and may be located above or below the water supply in a dry location. To vertically mount these units, it is best to do so with the motor on top. This will prevent water dripping on the motor in the event of a leak. Place pump on a solid surface and secure with four mounting screws; be careful not to compress the rubber grommets, which act as vibration dampers.
Adblue pump AC assembled:
Test machine:
Q: What's your main products of your company?
A: We specialized in all kinds of water pump(drinking water pump,micro gear pump,high performance diaphragm pump,Marine pump,RV pump )for over 10 years with excellent quality and competitive
Q:How can I choose the most suitable pump?
A: Please tell me your detailed flow rate, voltage, application and so on, then I will match the most appropriate pump for you, or you can choose the exact model in the product manual.If you don’t know the details for the pump, tell us the usage, must suitable model will be recommended.
Q: What's your payment way?
A: Usually we accept T/T ,Western Union or PayPal.
Q: What's your delivery time?
A. 1.The stock samples can be sent to you within 3-5days by international express after received
2.The batch order can be shipped to you in about 10-15days after order confirmation (by air or by sea).
Q: How long is your pump lifetime?
A: Pump lifetime mainly depends on motor lifetime,we have DC brush, brushless, coreless brushless motor For your choice, the pump warranty is 12 months.we can supply 1% spare parts for after service.
Trade manager: cn1501674438
Company Profile
YouMe Electric Co., Ltd is a leading company that mainly manufactures and trades precision pumps and flow control components. Since 2010, we have provided innovative, high-quality products with reasonable price for a wide range of fluid control applications.
Our product engineers work closely with customers to meet their precise performance requirements:
-- We have devoted on adblue /def dispenser system since 2008 cooperating with adblue liquid factories & distributers in Europe & Asia.
-- Each product has been tested on functionality and performance, and the flow meters are calibrated piece by piece after complete assembly in workshop before delivery.
-- Our new plus-bottled water dispenser design was customized with convenience - the pump automatically shuts off when the water source is depleted, and automatically restart when water is restored. This assures damage free to the appliance when running dry.
Our products are widely used in a varity of industries including: Adblue / DEF dispenser, Water Treatment and Purification, Biotechnology (Lab water), Medical, Floor Care, Automotive, Road Construction & Maintenance, Beverage/Foodservice, RV/Marine, Agriculture, and Alternative Energy (Solar & Fuel Cell). We directly base on a factory with OEM in over forty countries, and globally deliver our products on time through our distribution network.
