seed oil refining equipment 2016
- 20 Set / Sets per Month
- Qingdao
- T/T
Product Details
Type: | oil refining equipment | Use: | oil refining | Certification: | BV, ISO9001, CE, etc... |
Place of Origin: | Henan, China | Brand Name: | QIE | Model Number: | niger seed oil refining equipment |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
seed oil refining equipment 2016
Port:Qingdao or the nearest one
Packaging Details:International standard usually use wooden case, changed with the reqiurements
Delivery Detail:45-60 days
niger seed oil refining equipment
niger seed oil refining equipment Automatic Control System
Our company has applied the automatic control system with advancedness, security, reliability into the pretreatment, extraction, refining and fractionation in large oil plants. For its application in automatic control system, it can control the production in the entire workshop and monitor the operational status of each device by controlling the computer terminals in the room. One person only can operate the entire workshop, with efficient production management. It has reduced the production cost greatly and improved the management efficiency.
niger seed oil refining equipment Introduction :
Alkali hot water
Crude oilfiltermireactormireactorcentrifugal separationoil residue
Phosphoric acid hot watermi
degumming oilcoolerdrycentrifuge separationmialkali liquor
vacuum steam jet pumpsteam citric acid
bleaching earthmidecoloringfilterdecoloring oilmiheat
refined oilfiltercooldeodorizingvacuum
niger seed oil refining equipment -Main Processes Introduction
Neutralization of niger seed oil refining equipment : the crude oil is output by the oil feed pump from the oil tank, and net enters the crude oil heat echanger to recover part of heat after metering and then is heated to the required temperature by the heater. After that, the oil is mied with the metered phosphoric acid or citric acid from phosphate tank in the gas miture (M401), and then enters the conditioning tank (R401) to make the non-hydratable phospholipids in oil change into the hydratable phospholipids. Add the alkali for neutralization, and the alkali quantity and alkali solution concentration depend on the quality of the crude oil. Through the heater, the neutralized oil is heated to the temperature (90C) suitable for centrifugal separation to remove the phospholipids, FFA and other impurities in the crude oil. Then the oil goes to the washing process.
Washing of niger seed oil refining equipmentthere is still about 500ppm soap in the neutralized oil from the separator. To remove the remaining soap, add into the oil about 5~8% hot water, with water temperature 3~5 C higher than the oil generally. To achieve more stable washing effect, add phosphoric acid or citric acid when washing. The re-mied oil and water in the mier is heated to 90-95C by the heater, and then enters the wash separator to separate the remaining soap and most water. The water with soap and oil enters into oil separator to separate out oil in the water. Further catch the oil outside, and the waste water is discharged to the sewage treatment station.
Vacuum drying stageof niger seed oil refining equipment there is still moisture in the oil from the wash separator, and the moisture will affect the stability of the oil. So the oil at 90C should be sent to vacuum drier to remove the moisture, and then the dehydrated oil goes to the decoloring process. Finally, pump out the dry oil by canned pump.
niger seed oil refining equipment
Decoloring Process of niger seed oil refining equipment :
The main function of decoloring process is to remove oil pigment, residual soap grain and metal ions. Under negative pressure, the mechanical miing method combined with steam miing will improve the decoloring effect.
picture of niger seed oil refining equipment
niger seed oil refining equipment
1 Engineers to the scene to guide the installation;
2 Online question reply;
3 The warranty period of 12 months;
Our engineers in guiding workers how to operate the machine:
For further questions,please contact us by using the contacts below!!!
Thank you!!!
Attn: Amyliu
Zhengzhou Qi'E Grain & Oil Machinery Co., Ltd.
Web: /
Tel: +86-371-55606731
Fax: +86-371-67758097
Mobile: +86-138 3854 0385
Skype: amyliuqie
