Brass Wire Mesh Cloth/ Mesh Ironing Cloth/ Mesh Wash Cloths

Brass Wire Mesh Cloth/ Mesh Ironing Cloth/ Mesh Wash Cloths thumbnail-1
Brass Wire Mesh Cloth/ Mesh Ironing Cloth/ Mesh Wash Cloths thumbnail-2
Brass Wire Mesh Cloth/ Mesh Ironing Cloth/ Mesh Wash Cloths thumbnail-3
Brass Wire Mesh Cloth/ Mesh Ironing Cloth/ Mesh Wash Cloths photo-1
Brass Wire Mesh Cloth/ Mesh Ironing Cloth/ Mesh Wash Cloths photo-2
Brass Wire Mesh Cloth/ Mesh Ironing Cloth/ Mesh Wash Cloths photo-3
US$ 2.5 - 3.6 MOQ: 200 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
YS
Model Number:
YS-S-66
Contact Supplier Request Quote Chat Now
Anping Yuansheng Mesh Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
TianJin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name YS
Model Number YS-S-66
Material Other, Brass Wire, Brass Wire
Application Filter
Type Woven

Brass wire mesh cloth/ mesh ironing cloth/ mesh wash cloths


Brass Wire Mesh Cloth Specification

Material: Brass wire, phosphor bronze wire, or copper wire

Application: Seperation and sifting kinds pellet, grain, porcelain earth and glass, chinaware printing, filter liquid, etc. Specifications: brass wire cloth 6mesh/inch-160mesh/inch; copper wire cloth 10mesh/inch-60mesh/inch; phosphor bronze wire cloth 120mesh-360mesh/inch Width:0.914M, 1M, 1.5M Length/roll:30M

Weaving methods: Plain weave, twill weave or Dutch weave.

We are capable of supplying brass wire mesh from 1-200mesh, and phosphor bronze wire mesh from 1-500mesh. The following specifications are listed for your reference.

Mesh Wire Dia. (MM) Opening(mm)
SWG mm inch
6mesh 22 0.711 0.028 3.522
8mesh 23 0.610 0.024 2.565
10mesh 25 0.508 0.020 2.032
12mesh 26 0.457 0.018 1.660
14mesh 27 0.417 0.016 1.397
16mesh 29 0.345 0.014 1.243
18mesh 30 0.315 0.012 1.096
20mesh 30 0.315 0.0124 0.955
22mesh 30 0.315 0.0124 0.840
24mesh 30 0.315 0.0124 0.743
26mesh 31 0.295 0.0116 0.682
28mesh 31 0.295 0.0116 0.612
30mesh 32 0.247 0.011 0.573
32mesh 33 0.254 0.010 0.540
34mesh 34 0.234 0.0092 0.513
36mesh 34 0.234 0.0092 0.472
38mesh 35 0.213 0.0084 0.455
40mesh 36 0.193 0.0076 0.442
42mesh 36 0.193 0.0076 0.412
44mesh 37 0.173 0.0068 0.404
46mesh 37 0.173 0.0068 0.379
48mesh 37 0.173 0.0068 0.356
50mesh 37 0.173 0.0068 0.335
60X50mesh 36 0.193 0.0076 -
60X50mesh 37 0.173 0.0068 -
60mesh 37 0.173 0.0068 0.250
70mesh 39 0.132 0.0052 0.231
80mesh 40 0.122 0.0048 0.196
90mesh 41 0.112 0.0044 0.170
100mesh 42 0.012 0.004 0.152
120X108mesh 43 0.091 0.0036 -
120mesh 44 0.081 0.0032 0.131
140mesh 46 0.061 0.0024 0.120
150mesh 46 0.061 0.0024 0.108
160mesh 46 0.061 0.0024 0.098
180mesh 47 0.051 0.002 0.090
200mesh 47 0.051 0.002 0.076





Brass wire mesh cloth/ mesh ironing cloth/ mesh wash cloths

:

Brass wire mesh cloth/ mesh ironing cloth/ mesh wash cloths

Brass wire mesh cloth/ mesh ironing cloth/ mesh wash cloths
