Active short range rfid reader desktop with Impinj chip inside
Active short range rfid reader desktop with Impinj chip inside
1. Product Description
F5002H is a high end desktop UHF RFID reader/writer with USB interface, which is embedded the M2210 module and -2dBi/2dBi ceramic antenna. Its reading range can be up to 0.5 meter.
F5002H adopts plastic case, it is compact, small, portable and durable and suitable for desktop application for its rapid and precise reading/writing performance
2. Product Advantage
Active short range rfid reader desktop with Impinj chip inside
1. Employed IMPINJ R2000 RF Chips, up to -82dbm receiving sensitivity and the highest performance in this field makes this module more suitable for harsh application environment.
2. Low power consumption, brilliant performance.
3. Provide the most comprehensive functions SDK and ports, easy to integrate RFID software.
4. Adopted integrating RF chip, module performance is more stable, and more suitable for harsh application environment.
5. The use of carrier wave cancellation technology makes the tags reading more accurate and reading scope wider.
6. Enhanced noise suppression function for reliable data capturing.
7. High precision return signal strength (RSSI).
8. Excellent performance of anti-interference
9. Plastic case, small and portable, rugged and durable.
3. Technical Specifications
Active short range rfid reader desktop with Impinj chip inside
| NO. | Name | Parameters |
| 1 | Working Voltage | DC +12V |
| 2 | Working Temperature | -25~+65°C |
| 3 | Working Humidity | ≤95%(+25°C) |
| 4 | Storage Temperature | -40~+80°C |
| 5 | Tag Protocol | EPCglobal UHF Class |
| 1 Gen 2 / ISO 18000-6C | ||
| 6 | Working Frequency | 840--960 MHz |
| 7 | Supporting Working Areas | China 1, China 2 |
| US, Canada and other regions | ||
| following U.S. FCC | ||
| Europe and other regions | ||
| following ETSI EN 302 | ||
| 208 with & without LBT regulations | ||
| Japan | ||
| Korea | ||
| Malaysia | ||
| Taiwan | ||
| 8 | Output Power | Software adjustable, step |
| interval 1.0dB, maximum +30dBm | ||
| 9 | Output Power Flatness | ±0.2dBm |
| 10 | Receiving Sensitivity | -82dBm |
| 11 | RF Port Standing Wave | ≤1.5 |
| 12 | Reading Range | Maximum 0.5m (relate to tags type, transmitted |
| power and application environment) | ||
| 13 | Writing Range | Maximum 0.2m (relate to tags type, transmitted |
| power and application environment) | ||
| 14 | Interface Communication Rate | 115200bps |
| 15 | Working Temprature | Support |
| Detection | ||
| 16 | RSSI | Support |
| 17 | Antenna Type | -1dBi ceramic antenna |
| 18 | Communication Port | USB |
| 19 | Buzzer | Yes |
| 20 | LED | Red(power indicator) |
| Green(status indicator) | ||
| 21 | Enclosure | plastic case |
| 22 | Size | 12.0*12.0*3.0CM |
| MOQ | 1 ea |
| Package | Foam & Carton |
| Devlivery terms | FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery |
| Delivery time | 7 working days for common quanlity |
| Payment type | L/C,T/T,Western Union,Paypal |
| Supply ability | 50K pcs/month |
| Port | Shenzhen |
Warrenty period: 12 months upon the product's received date.
More products to choose:
Our company's profile & view
| Business type: | Manufacturer,Trading company |
| Main Products: | RFID Reader,RFID Tag,RFID Module,UHF reader,active reader |
| Location: | Guangdong, China (MainlaManufacturer, Trading Companynd) |
| Year Established: | 2011 |
| Year start exporting: | 2011 |
| Number Of Employees: | 101 - 200 People |
| Total Revenue: | US$2.5 Million - US$5 Million |
| Main Markets: | Eastern Europe, Mid East, North America, Western Europe, South America |
| Average Lead Time: | 7 Day(s) |
Our company's certification
Who we(Sanray) are?
Shenzhen Sanray Technology Co., Ltd. is a high-tech enterprise specializing in the development, manufacture and sales of top-quality UHF RFID products and active RFID products. We focus on the development and sales of UHF RFID modules, readers and tags, and 2.45GHz RFID readers, tags, etc. We spare no efforts on the supply of RFID products with various functions and high reliability to our cooperation partners. Also we provide the clients in fields of libraries, financial units, mass production and logistics with comprehensive intelligentized solutions.
How to order
Please chat with us through TradeManager or click "contact supplier" to leave massage about the quantity,special modelyou want or your requirement. Then we will reply to you ASAP.
After we confirm all detailed information, we Will Make PI (Performa Invoice) for you to confirm the order if you need.
Payment terms
1. We accept PayPal, Western Union and Bank transfer.
2. 30% deposit and 70% before shipping.
3. No payment collection. We only can deliver goods after getting full payment.
