Desktop RFID Reader 860 to 960MHz UHF RFID Reader Writer Short Distance Intelligent Reader & Tag
1. Product Description
F5002H is a high end desktop UHF RFID reader/writer with USB interface, which is embedded the M2210 module and -1dBi ceramic antenna. Its reading range can be up to 0.5 meter.
F5002H adopts plastic case, it is compact, small, portable and durable and suitable for desktop application for its rapid and precise reading/writing performance
2. Product Advantage
1. Employed IMPINJ R2000 RF Chips, up to -82dbm receiving sensitivity and the highest performance in this field makes this module more suitable for harsh application environment.
2. Low power consumption, brilliant performance.
3. Provide the most comprehensive functions SDK and ports, easy to integrate RFID software.
4. Adopted integrating RF chip, module performance is more stable, and more suitable for harsh application environment.
5. The use of carrier wave cancellation technology makes the tags reading more accurate and reading scope wider.
6. Enhanced noise suppression function for reliable data capturing.
7. High precision return signal strength (RSSI).
8. Excellent performance of anti-interference
9. Plastic case, small and portable, rugged and durable.
NO. |
Name |
Parameters |
1 |
Working Voltage |
DC +12V |
2 |
Working Temperature |
-25~+65°C |
3 |
Working Humidity |
≤95%(+25°C) |
4 |
Storage Temperature |
-40~+80°C |
5 |
Tag Protocol |
EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C |
6 |
Working Frequency |
840--960 MHz |
7 |
Supporting Working Areas |
China 1, China 2 US, Canada and other regions following U.S. FCC Europe and other regions following ETSI EN 302 208 with & without LBT regulations Japan Korea Malaysia Taiwan |
8 |
Output Power |
Software adjustable, step interval 1.0dB, maximum +30dBm |
9 |
Output Power Flatness |
±0.2dBm |
10 |
Receiving Sensitivity |
-82dBm |
11 |
RF Port Standing Wave |
≤1.5 |
12 |
Reading Range |
Maximum 0.5m (relate to tags type, transmitted power and application environment) |
13 |
Writing Range |
Maximum 0.2m (relate to tags type, transmitted power and application environment) |
14 |
Interface Communication Rate |
115200bps |
15 |
Working Temprature Detection |
Support |
16 |
RSSI |
Support |
17 |
Antenna Type |
-1dBi ceramic antenna |
18 |
Communication Port |
USB |
19 |
Buzzer |
Yes |
20 |
LED |
Red(power indicator) Green(status indicator) |
21 |
Enclosure |
plastic case |
22 |
Size |
12.0*12.0*3.0CM |
We also have different kinds of UHF RFID devices, such as modules, readers, antennas, inlays, metal tags, etc.. Pls feel free to contact us for datasheet, catalogue or price. Hope we can be of assistance and provide you our best products and solutions.
- Are you manufacturer?
Yes.We are of course manufacturer with our own R&D team and factory in shenzhen.
- Can you provide application software for the hardware?
We provide free SDK and User manual of all API to support your development or programming.
- What is the warranty?
The warranty time is 1 year without man-made damage.
- Does the device have the language default as English?
Of course, our device supports multi-language such as English,Spanish, Portuguese ,French, German,Polish,Japanese, Russian and so on.
- Can your device install the Android Apps that our customers provide?
No problem. Just send us your Apps which you need to get the liscense of the apps and then our Engineers can do that for you.
If you have any other question about our products,please don’t hesitate to contact us.We will be more than happy to serve you.
Shenzhen Sanray Technology Co., Ltd. is a high-tech enterprise specializing in the development, manufacture and sales of to quality UHF RFID products and active RFID products. We focus on the development and sales of UHF RFID modules, readers and tags, and 2.45GHz RFID readers, tags, etc. We spare no efforts on the supply of RFID products with various functions and high reliability to our cooperation partners. Also we provide the clients in fields of libraries, financial units, mass production and logistics with comprehensive intelligentized solutions.
