China mining rotary Industrial charcoal sieving machine 008613838391770
Charcoal sieving machine, is consist of five parts as drum, frame, hopper, reducer and motor. After the broken stone into the drum, on the one hand, materials being screened along with the rotation of drum, on the other hand, the bigger materials flow forward along the direction of slope and be separated by the screen with different number of meshes. The different materials fall into different hopper and then be sent to different finished product stacks by manpower or belt conveyor.
Working basis of the charcoal sieving machine:
The screen is operated by electric motor to drive vibrator witheccentric mass via delta belt, allowing screen box to virbrate, with the motional orbit of the screen box being circular. The screen is composed of screen box, vibrator, spring damping device, supporting under frame and others.
Main technical data of the charcoal sieving machine:
| Model | Screen surface area | Capacity | The outer sieve dia. | Length | Power |
| GTS-3 | 3m² | 10.4 t/h | Φ1200mm | 3.5m | 1.5kw |
| GTS-5 | 5m² | 13.8 t/h | Φ1200mm | 4m | 2.2kw |
| GTS-10 | 10m² | 27.8 t/h | Φ1400mm | 5m | 4kw |
| GTS-15 | 15m² | 47.7 t/h | Φ1500mm | 6m | 7.5kw |
Features of the charcoal sieving machine:
1. Large processing capacity for separating out multiple grades
2. Simple structure, smooth running, low noise, less blocking of mesh screen
3. Easy installation and maintenance
4. ISO9001:2008, CE certification, SGS report
Gongyi Xiaoyi Mingyang Machinery Plant is located in Zhengzhou City,which is the biggest manufacturing base of charcoal making machinery. And we are the one of the earliest and largest manufacturers of renewable fuel & energy equipment and related machinery. After 15 years development, now our company becomes an independent economic entity with the integration of science, engineering and trading department. Our products are widely accepted in both domestic and world markets, and also are exported to more than 30 countries, such as England, Russia, Sweden, Poland, Iran, Sudan, South Malaysia, Indonesia, Vietnam,etc. We have lots of experience to export and cooperate with all over the world, and we also sincerely welcome you to come to our factory to visit and watch our products and factory.
We have many kinds of certifications, famous in domestic and overseas, such as ISO Approved, CE Approved, SGS, BV and other certifications in our country. Such as Alibaba certifications, Made-in China, etc. You can find our factory and watch our products in many websites, We win in the strength, win in the quality and win in the service. This is why our clients choose us.
1. Contact me first and make a deal;
2. Sign order and then pay the down payment;
3. Receive the down payment, we arrange our factory to produce the machines;
4. After finished the manufacturing, we test, examine the machines;
5. The last step is to transport the mahcines to your country port. The whole line is finished.
1. Pre-sale service: according to your special needs, design and manufacture products for you, provide you with project design, process design, purchase program.
2. On sale: accompany you to check the performance of the machine.
3. After-sale service: we will send engineers to install the equipments to put them into use as soon as possible, commissioning and training operators on site.
Contact: Ms. Bella Ren
Cell: 0086-13838391770
Skype: bella616919
Trademanager: cn1510973586
Wechat: belladaner
Whatsapp: 008613838391770
