Energy-saving Agricultural Mobile Sprinkler Irrigation System

1.PE water pipe
Diameter: 75mm,length: 400m,burst pressure >2.0Mpa,tensile strength >16.5Mpa,service life: 15 years.
The PE pipe is a kind of high-tech products, one end of it is connected on the reel, and through the horizontal axis to water supply,the other end is connected with the sprinkler car.

2.High quality domestic spray gun
Vertical rocker type spray gun and turbine worm type spray gun.

3.Impact type water turbine
Rotate speed:1050 r/min,with functions of automatic speed control.

4.Multi-function two-speed gearbox transmission

It is the control system of the sprinkler irrigation machine.

5.Automatic arrangement of PE pipe guide device

It is about a thread guide rod and can shift the drive, it can ensure that the PE pipe automatic recovery, each layer are volume very neatly.

6.Speed compensation mechanism

Through the drive mechanism automatically adjust the water turbine opening,compensation the speed change of the reel rotating line,when at a constant speed, then locking the five-star nut.

7.Automatic parking safety device

It can realize the transmission system of on-off, brake, variable speed, safely and quickly recycle, automatic stop function.

8.Rack

Welded by rectangular pipe,good rigidity.All structures are processed by hot dip galvanized, with good anticorrosion performance,also it can rotate 360 degrees.

9.Reel

Exclusive use pickling, phosphating, high temperature treatment process of the bake lacquer and acrylic decoration process, to ensure durable, do not fade, beautiful and high-grade.

10.Sprinkler car

Track width adjustable and can be equipped with heighten rack(irrigation tall crops).

Advantages

Spray gun and truss can be optional.

1.Formulating an irrigation scheme for users.
