Two Stage Water Cooling Plastic Processing Machinery
Contact: Ms.Alice
Skype: dhella63
Mobile: 008613838255120
WhatsApp/Viber: 008613838255120
Brief Info of Plastic Recycling Machine
Waste plastic recycling pelletizing machine is used to make salvage polypropylene, polystyrene materials into pellets. The machine can press and pull the material into strip with the high temperature, the plastic strip can be cut into pellet by the cutting machine.
Product Effects of Plastic Recycling Machine
Machine Adventages of Plastic Recycling Machine
1. Good looking in surface, color coordination, spray-painted solid.
2. Hopper, crushing room, misreported is disserted, easy to dumpster gate.
3. The crushing room use noise arrester, to lower noise.
4. Pulley with guards, so it is safe and reliable.
5. Cleaning and insurance
6. The motor has a protective device and power chain protection system.
Raw Material of Plastic Recycling Granule
Plastic recycling pelletizing machine is mainly used in extruding soft and hard thermoplastics, such as polyviylchloride(PVC),polyethylene, plastic bottle, plastic film and others.
Technical Parameters of Plastic Recycling Granule Making Machine
Adopts screw with mature screw structure. In the light of different raw materials, different mixing elements are adopted to provide the extruder with high speed and high output and make the processed material mixed uniformly, radial temperature range small, and formed products little deformation. Equipped with relevant die head and auxiliary machine it could be used to process PE/PP/PA/PC/ABS pipes, profiles, sheets/boards, as well as granules.
ONE SCREW MACHINE | |||||
Model |
DHPP-90 |
DHPP-100 |
DHPP-110 |
DHPP-120 |
DHPP-135 |
Screw Diameter |
90mm |
100mm |
110mm |
120mm |
135mm |
Screw Ratio |
22:1(L:D) |
22:1(L:D) |
22:1(L:D) |
22:1(L:D) |
22:1(L:D) |
Screw Speed |
10-110rpm |
10-110rpm |
10-110rpm |
10-110rpm |
10-110rpm |
Motor Power |
18.5-22kw |
22kw |
30kw |
37kw |
55kw |
Main Output |
60-80kg/h |
70-90kg/h |
90-110kg/h |
100-130kg/h |
160-180kg/h |
Weight |
2t |
2.1t |
2.2t |
2.5t |
3.5t |
Dimensions |
4800*1250*1100 |
4900*1300*1200 |
5000*1350*1300 |
5200*1400*1350 |
5500*1450*1500 |
—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/—/
TWO SCREW MACHINE | |||||||
Model |
DHPP-100/90 |
DHPP-120/95 |
DHPP-120/100 |
DHPP-120/110 |
DHPP-135/120 |
DHPP-150/125 |
DHPP-160/130 |
Screw Diameter |
100mm, 90mm |
120mm, 95mm |
120mm, 100mm |
120mm, 110mm |
135MM, 120MM |
150MM, 125MM |
160MM, 130MM |
Screw Ratio |
12:1-8:1(L:D) |
12:1-8:1(L:D) |
15:1-8:1(L:D) |
18:1-8:1(L:D) |
15:1-8:1(L:D) |
22:1-10:1(L:D) |
20:1-10:1(L:D) |
Screw Speed |
10-110rpm |
10-110rpm |
10-110rpm |
10-110rpm |
10-110rpm |
10-110rpm |
10-110rpm |
Motor Power |
15kw;7.5KW |
18.5kw;7.5KW |
22kw;11kw |
37KW;15KW |
45kw;15kw |
55kw;18.5kw |
75kw;15kw |
Main Output |
60-80kg/h |
80-100kg/h |
120kg/h |
130-150kg/h |
150-170kg/h |
200-220kg/h |
250-280kg/h |
Weight |
1.8t |
2.0t |
2.4t |
3t |
3.5t |
3.8t |
4.5t |
Dimensions |
3000*1000*1500 |
3400*1200*1550 |
3700*1200*1550 |
3600*1200*1550 |
4100*1300*1600 |
4500*1300*1650 |
5500*1300*1700 |
Working Principle of Plastic Recycling Machine
Process flow of plastic recycling pelletizing machine/plastic granulator/plastic pelletizer:
Conveyor→ raw material compactor(feeder)→ Extruding system→ Die-head and High speed Net exchanging system→ water ring pelletizing system/noodle type pelletizing system→ dewatering machine→ vibrating sieve→ Air Blower → Storage hopper
Machine Show of Plastic Recycling Machine
We could provide extruders of different configurations according to different requirements of customers, for example, AC frequency conversion control, DC digital control or PLC control are for customer's option. The customer could choose different models of reduction box according to motor of different power. Also they could choose bearings made in China or made in foreign countries.
Machine Features of Plastic Recycling Machine
- Adopting imported fiber laser generator.
- Perfect beam quality.
- Fiber laser marking machine can make deep marking up to 1.0mm on stainless steel and aluminum. While YAG and Diode machines could only mark 0.2mm-0.3mm.
- Fast marking speed.
- Our laser education courses are designed to provide you with a solid foundation of fundamental laser marking skill sets to immediately gain a revenue impact with your laser marking machine.
- The software can import images from standard graphic design software packages, including Adobe Illustrator and CorelDraw.
- Equipment comprehensive performance is stable.
- All-in-one machine with manual focusing system.
- Use Integrated Air Cooling.
- No maintenance needed.
- No consumption needed.
- Consuming little to no energy when not active. Energy saving.
- Great for continuous working.
- Long lifetime.
- For long-term consideration, the cost is much lower than other laser marking machine.
1. The recycling plastic pelletizing machine will be packaged by export standard wooden case or upon customer's request.
2. All the machines will be adjusted and tested before shipping.
Pre-sale:
- Suggest to client suitable models of as customer need.
- Introduce machine's structure and features in detail, explain the price component.
- Answer client concerned questions.
After-sale:
- Documents and certificate available in time.
- One year guarantee for whole machine.
- 24 hours technical support by e-mail.
- Calling or door-to-door service.
- User manual and detailed Videos/CD.
Q: How about the quality of your products?
A: Our machines are manufactured strictly according to national and international standards, and we take a test on each equipment before delivery.
Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passports.
Q: How long is the delivery?
A: Delivery time: within 10-15 working days after receive the deposit.
For more information, pls contact me freely and I will reply you as soon as possible!
We not only provide customers with cost-effective high quality products, but also provide first-class service and support solutions.
