Product Description
The product is widely used in various ores, cement, refractories, bauxite clinker, carborundum, glass raw materials high-hard, special hard material, the crushing fields. In the mechanism building sand, stone and various metallurgical slag crushing is widely used, and compared to other types of crushers yield high efficiency. compound crusher (composite broken) crushing ratio greater degree, the maximum reduction ratio can reach the particle size can be adjusted, without plate hammer, liner wear impact; without sieve set, crushing high moisture content, clay content when large material clogging; adopt a flexible adjustment mechanism into the non-broken material can be automatically discharged, will not cause damage to the equipment; bearing horizontal arrangement, long life, high temperature materials can be broken (such as cement clinker); this machine rotor body unique structure, crushing the material, the rotor body almost no wear and tear; after the cavity is provided with a screw or hydraulic opening mechanism, not from the master device, you can easily replace wearing parts.
Principle:
Material from the top of the machine vertical high-speed rotation of the impeller, centrifugal force at high speed, with another part of the umbrella in the form of diversion of materials around the impeller produces high-speed impact and crushing, the material impact on each other, then they will in the impeller and chassis material between each other to form a vortex repeatedly impact, friction and grinding, direct discharge from the bottom to form a closed loop several times, controlled by the screening equipment to achieve the required product size.
Features:
Compared with jaw crusher, capacity of vertical compound crusher is higher, so it has been widely applied quickly. Vertical compound crusher with crushing ratio, wide crushing moisture content is high, the high moisture content of the material for processing is ideal, the particle size can be adjusted without sieve set, containing a large quantity of sediment material will not congestion, non-broken material into the body can be automatically discharged, will not cause damage to the equipment. The vertical compound crusher high production efficiency, unique structure, smooth operation, low noise, maintenance side cases, opening the doors of work you can easily replace the damaged pieces.
TECHNICAL DATA:
| Model | Feeding size (mm) | discharging size (mm) | Capacity (t/h) | Rotating speed of main shaft (r/min) | Motor power (kw) | Overall dimension (mm) |
| PFL-800 | <100 | <3-5 60-90% | 10-20 | 934 | 22 | 2100*1200*1700 |
| PFL-1000 | <120 | <3-5 60-90% | 20-40 | 769 | 37 | 2600*1400*1900 |
| PFL-1250 | <150 | <3-5 60-90% | 40-70 | 530 | 75 | 2800*1600*2100 |
| PFL-1500 | <180 | <3-5 60-90% | 70-100 | 495 | 132 | 3100*1900*2200 |
| PFL-1750 | <200 | <3-5 60-90% | 130-190 | 424 | 160 | 3710*2360*2390 |
| PFL-2000 | <220 | <3-5 60-90% | 100-160 | 370 | 185 | 4100*2660*2620 |
Stone Gallery
Customer visits
Factory show
Dewo Service
Our service
Dewo can provide turkey service for customers, such as engineering consultation, engineering design, equipment manufacturing, packing & transportation, installation & commissioning personnel training etc.
About Spare Parts
Dewo Machinery will be dedicated to provide our customers with genuine spare parts with high quality. With our technological advice, the life cycle of your machine can be prolonged and sustained significantly with high effectiveness.
About Training
Dewo machinery could offer excellent facilities and comfortable environment and training services to different customers. The training should include product training, safety training, operation training, maintenance know-how, technical know-how training, and regulations training, etc. All of the training is customized to fulfill every customer’s expectations. Training programs can be conducted in our workshop, or at customer’s site.
About Installation and Commissioning
Dewo are able to guide the overall installation of whole set production line, including crushing production line and cement equipment production line, etc., which will allow you to start the normal operation of equipment immediately. After installation,we will make inspection of the whole machine commissioning and operation condition and provide you testing data report of installation.
