1500x12000 Rotary Drum Drier Machine Price

1500x12000 Rotary Drum Drier Machine Price thumbnail-1
1500x12000 Rotary Drum Drier Machine Price photo-1
US$ 22,538 - 30,769 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Dewo
Model Number:
1500x12000
Contact Supplier Request Quote Chat Now
Henan Dewo Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Tianjin Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name Dewo
Model Number 1500x12000
Condition New
After-sales Service Provided Engineers available to service machinery overseas
Company Information

Henan Dewo Machinery Co.,Ltd. (hereinafter refer as Henan Dewo) is a professional mining machinery manufacture with ISO, CE Certificate, specialized in produce and develop various kinds mining machines for over 20 years, since 2008 the International Trade Department opened, we had export 44 countries and regions, rotary drying machines have been  exported to Korea, Vitenam, Malaysia, Pakistan, Turkey, Spain,Azerbaijan, Russia, Kazakhstan, Uzbekistan, Bolivia,  Panama and so on, with successful projects and excellent quality we have very good  reputation from our clients.


1500x12000 Rotary Drum Drier Machine Price

1500x12000 Rotary Drum Drier Machine Price
Product Description



The rotary dryer is a type of industrial dryer employed to reduce or minimize the liquid moisture content of the material it is handling by bringing it into direct contact with a heated gas.


Product Uses



  • Powder & particle: Sands, limestone, stones, clay, mineral concentrate,coal, iron sulphate, filter cakes, fly ash, gypsum etc.
  • Damp and sticky material: Coal slime, sewage sludge, bentonite, Kaolin etc.
  • Corrosive material: Distillers'grains, Fertilizer, animal dung, slag etc.
  • Biomass material: Sawdust, wood chips etc.

  1500x12000 Rotary Drum Drier Machine Price
Working Principle



The dryer is made up of a large, rotating cylindrical tube, usually supported by concrete columns or steel beams. The dryer slopes slightly so that the discharge end is lower than the material feed end in order to convey the material through the dryer under gravity. Material to be dried enters the dryer, and as the dryer rotates, the material is lifted up by a series of internal fins lining the inner wall of the dryer. When the material gets high enough to roll back off the fins, it falls back down to the bottom of the dryer, passing through the hot gas stream as it falls. This gas stream can either be moving toward the discharge end from the feed end (known as co-current flow), or toward the feed end from the discharge end (known as counter-current flow).

 1500x12000 Rotary Drum Drier Machine Price


Technical Parameter



Model

Capacity(t/h)

Main motor

Main gear box

Weight(t)

Power(kw)

Model

Model

Speed reduction ratio

ø1.2*10

2.5

7.5

Y160M-R3

ZL50-16-I

-----

13.5

ø1.5*12

3.3-4.9

10

Y160L-6-B3

JZQ500-III-2F

-----

18.9

ø1.5*12

4-6

15

Y200L1-6

JZQ500-III-2F

-----

17.8

ø1.8*12

4-6

18.5

Y160L-6

ZQ50-16II-2

16.46

22.83

ø2.2*12

7-12

18.5

Y200L7-6

JZQ650-III

31.5

37.6

ø2.2*14

7-12

22

Y200L7-6

JZQ650-III

31.5

40

ø2.2*16

12

30

Y225M-6

JZQ750-III

31.5

45

ø2.4*14

12

30

Y250M-6

JZQ750-III

31.5

51

ø2.4*18

10-13

37

Y250M-6

ZL85-13-I

27.16

54

ø2.4*20

10-14

37

Y250N-6

ZL85-13-I

27.16

54.14

ø3*20

25

55

Y250M-4

ZL100-16-I

41.52

78

ø3*25

32-36

75

YR280M-4

ZL100-16-I

41.52

104.9




Detailed Images

  1500x12000 Rotary Drum Drier Machine Price







1500x12000 Rotary Drum Drier Machine Price







1500x12000 Rotary Drum Drier Machine Price





About Us

Approved by the National Commerce Ministry, established in 2006, located in Zhengzhou city, Henan province, covering area about 300,000 square meters, with more than 260 employees which including R&D staffs more than 50 people, Henan Dewo is a comprehensive enterprise which integrates researching, manufacturing, market developing and service for mining crushing equipment, infrastructure equipment, ore beneficiation equipment and mining drying equipment.

1500x12000 Rotary Drum Drier Machine Price

1500x12000 Rotary Drum Drier Machine Price

1500x12000 Rotary Drum Drier Machine Price

1500x12000 Rotary Drum Drier Machine Price

FAQ

1500x12000 Rotary Drum Drier Machine Price

Q: For providing you the suitable quotation we need to know the following information:
A: 1.What is the raw material for the production line?
2. What is the capacity per hour you required?
3. What is the maximum input size of the raw material?
4. What is the output size and application for the final product? Once we get your answers, I can provide you the best quotation immediately.
Remarks: The price will depend on different models. Reply message you will get 5% discount price.
Q: What about Warranty of the products?
A: Dewo Machinery grants our customers a twelve-month-period warranty from the date of delivery for machines exported from us. During the warranty period, in case any defect of material or workmanship occurred with spare parts in normal operation, we will at our discretion replace or repair the defective parts freely.
Q: The reason you choose Dewo Machinery:
A: 1. Professional manufacturer of supplying mining crushing equipment, construction equipment, Ore beneficiation equipment and mining dryers.
2. Experienced and professional R&D team and manufacturing team;
3. Professional sales team consisted of dedicated, dynamic and innovative people with international version.
4. Professional logistics service ensuring safety and timely delivery of products all over the world through ocean, airline, road and railway.
