Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > Batch Mixing Machine Double Shaft Mixer/clay Mixing

Batch Mixing Machine Double Shaft Mixer/clay Mixing

Name: Batch Mixing Machine Double Shaft Mixer/clay Mixing
Brand: shuangying
SKU: 139130265
Availability: InStock

Batch Mixing Machine Double Shaft Mixer/clay Mixing thumbnail-1

Batch Mixing Machine Double Shaft Mixer/clay Mixing photo-1

US$ 1,000 - 10,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Mixer Type:

Screw

Application:

Powder

Contact Supplier Request Quote Chat Now

Jiaozuo Double Eagle Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Mixer Type Screw

Application Powder

Additional Capabilities Milling

Place of Origin Henan, China

Brand Name shuangying

Model Number SYSZ3500*750

Max. Loading Capacity 1200L

Voltage 380V

Power(W) 30kw

Dimension(L*W*H) 5000*900*620mm

Certification ISO

Warranty 1year

After-sales Service Provided Overseas service center available

Introduction:

Double-shaft Charcoal mixer mainly consists of casing, spiral shaft assembly, drive equipment, piping, cover plate, chain cover and other parts(see the ramdom for figure), the concrete structure performance characteristics are as follows:

the shell is mainly composed of plates and steel structure, welding forming within the manufacturing plant, and compares with other parts together, dualaxis mixer is supported. Shell sealed tight, there would be no fly ash or ash leakage to the publish, and no ash leakage phenomenon, either.

Technical parameter:

Model	Output	Speed	Motor	Machine size	Machine weight
SYSZ2000*500	10-12T/h	35r/min	11KW	3100750500mm	1600kg
SYSZ2500*650	15-20T/h	35r/min	15KW	4200800620mm	2500kg
SYSZ3000*650	20-25T/h	35r/min	22KW	4700800620mm	3200kg
SYSZ3500*700	25-30T/h	35r/min	30KW	5000900620mm	3600kg
SYSZ4000*800	30-40T/h	35r/min	37KW	5800970640mm	3850kg
