Specifications
food peristaltic hose pump1.high efficiency food peristaltic hose pump.
2.capacity:25m3/h.
3.power:5.5kw.
4.high quality.
Factory price food peristaltic hose pump
Application:
1.Chemical industry, for various anti-corrosion paste and inorganic material;
2.Papermaking industry,for paper pulp and sulfur transfer
3.Paint coating,titanium dioxide, carbon dioxide and so on.
Working principle:
When a pair of roller rotate and squeeze the hose, the rotation and squeezing force will force the transported
material flow in single direction and with no back flow. After the material in hose is transported, the squeezed
hose will return to its normal shape by its elasticity and pressing force of side rollers. During this procedure,
the vacuum generated will suck the material into hose cavity, and then, the sucked material will be squeezed
by coming rollers and discharged from the output again.
Technical data:
model |
capacity |
pressure |
Power |
Hosepipe size |
RGB-65 |
≤15m3/h |
0.8Mpa |
4-5.5kw |
φ100×φ64×1800mm |
RGB-75 |
≤28m3/h |
0.8Mpa |
7.5-11kw |
φ116×φ76×1900mm |
RGB-100 |
≤50m3/h |
0.8Mpa |
18.5kw |
φ148×φ120×2500m |
Pictures:
The line:
Wooden case,or according to your requirement.
Zhengzhou Aix Machinery Equipment Co,.Ltd.is specialized in brick equipment for many years,our machine,such as:conveyor,Foam agent,Concrete Mixer, Foam Generator,Concrete pump,etc. And our machine export:Ukraine, Argentina, Bulgaria,Kenya,Jordan, Malaysia,Togo,Nigeria,etc.The goods was sold very well.Hope we can establish the longstanding relationship.
1. how can got food peristaltic hose pump ?
Dear, after your payment,we will arrange to delivery to your port, and we will send the clearance documents to you, you need find the import company to have you customs clearance,then you can got the machine.
2.In the using processing,if i have some problem, how to slove it ?
You can send me the email or call me, ans send me the picture or video to me,i will let our engineer help you solve it.
3.The terms of payment ?
T/T,Western Union,L/C,Escrow.
4.How long i can got food peristaltic hose pump ?
It according to different country, please tell me your destination port, then i will confirm it for you.
If you want to know more information,please contact me.
Mobile:0086-18237112101
Skype:aixmachinery
