134.2khz RFID animal Reader/RFID Scanner

Specifications

animal rfid reader
1. Frequency: 125/134.2Khz
2. Read all ISO animal tags
3. Pet Microchip Scanner
4. Rechargeable battery

134.2khz RFID animal Reader/RFID Scanner









1. Support all common ISO11784/11785 RFID animal tags;
2.Easy operation, reading with only one button;
3.The display comes with backlight for easy reading in dark environment;
4. Big memory to in store up to 8000pcs ID number data;
5. Directly read the history data under internal reading mode;
6.Low battery alarm function when battery power is lower than 7.8V;
7.Optional output interface for external antenna;
8. Standard USB interfaces to connect with computer for data uploading.
9.Color options: White, Black



Product Function

PRODUCT CODE	animal rfid reader
Frequency	134.2 ± 2 KHz
Standard and Protocol	ISO 11784/11785
Transmission Principle	FDX-B
C Type	T5577,EM4305,HITAG S256
Data Memory	330bits,512bits,256byte,1024bits
Reading Range	6-10cm by  handheld animal reader, 30-50cm upon long range reader
Operating Temperature	-25oC to 70oC
Storage Temperature	-40oC to 100oC
Weight	95 ± 20 mg for 2x12mm; 34mg for 1.4x8mm
Write Endurance	> 1,000,000 cycles
Memory Retention	> 20 years
Interface	USB
EMC	Not affected by Normal Electromagnetic Interference or X-Rays
Power Source	Battery Required



Our Advantage



• Designed especially for animal identification
• Embedded ICAR approved glass transponder
• Bio-compatible glass encapsulation
• Pre-sterilized and ready to use
• Individually packaged in a disposable needle
