Specifications
1)LWM:12.5-200mm2)SWM: 5-80mm
3)Thickness: 0.5-8mm
4) ISO9001:2008 good qality ,best price we offer
punch mesh
1.Hole Diameter:0.3-50mm
2.Plate Thickness:0.2-8mm
3.ISO9001:2000
4.Material:
Low carbon steel, stainless steel, stainless steel, aluminum steel, plywood, hip board, density board, plastic film, etc.
5.Hole shapes:
Round, rectangular, square, triangle, hexagonal, diamond, lightly pull scale, cross, slotted and special patterns to get special decoration results.
6.Feature:
The product has the advantages of resistant to acid, alkali, abrasion, pressure and bending. The mesh surface is flat and artistic with high brightness.
7.Application:
It is used as screening in pharmaceutical, petroleum, mine, machinery, battery, filtering to engine oil and diesel, indoor and outdoor decoration, making the crafts, production of steel and wood furniture, grain ventilation, acoustics unit in loudspeaker etc. Specify the thickness of the sheet, length of perforated metal sheets, size and shape of the perforation patterns and other relative information when you send your inquiry.
8.Specification: Special requirements are available.
Hole |
Hole |
Pitch |
Number of Hole |
Open Area |
In. No. |
In MM |
In MM |
Per Sq.Inch |
In % |
3.00 |
0.50 |
1.09 |
627.02 |
19.09 |
3.25 |
0.55 |
1.25 |
476.00 |
17.50 |
3.50 |
0.60 |
1.25 |
471.00 |
20.90 |
3.75 |
0.70 |
1.35 |
408.00 |
24.39 |
4.00 |
0.80 |
1.39 |
385.57 |
30.05 |
4.50 |
0.90 |
1.39 |
385.57 |
38.04 |
5.00 |
1.00 |
1.67 |
267.12 |
32.53 |
5.25 |
1.10 |
1.67 |
267.12 |
39.36 |
5.50 |
1.20 |
2.00 |
186.24 |
32.66 |
5.75 |
1.30 |
2.25 |
147.15 |
30.29 |
6.00 |
1.40 |
2.50 |
119.19 |
28.45 |
Send Inquiry to This Supplier
