Stainless steel welded wire mesh(manufacturer)

Specifications

Stainless steel wire mesh
1 Wire diameter: 0.4-4.0mm
2 Maximum width: 2.0m
3 Mesh Hole: 1/4"1/2" 3/4"3/8"5/8" 1" 2"











Features and Benefits of Stainless Steel Welded wire Mesh:

In comparison with the galvanized welded wire mesh, the stainless steel welded mesh offers better corrosion resistance performance. However, its price is a little higher. In addition, some of its other prominent advantages are mainly reflected as follows: firm welding spot, flat and bright surface, high tensile strength, good integrity, firm and durable structure, and rust resistance, etc. Moreover, the stainless steel welded mesh is processed by high-precision automatic equipment. Thus, even if the welded mesh suffers partial pressure or cutting, it will still not come loose.

Application :

Stainless steel welded mesh can be widely used in poultry breeding, civil construction, machine protection, highway, railway, sports venue fencing, road green belt protection and so on.

Specification :

Mesh		Wire Diameter
In Inch	In MM	Wire Gauge	In MM
1/4″ x 1/4″	6.4mm x 6.4mm	22#-24#	0.7mm-0.6mm
3/8″ x 3/8″	10.6mm x 10.6mm	19#-22#	1.0mm-0.7mm
1/2″ x 1/2″	12.7mm x 12.7mm	16#-23#	1.6mm-0.6mm
5/8″ x 5/8″	16mm x 16mm	18#-21#	1.2mm-0.8mm
3/4″ x 3/4″	19.1mm x 19.1mm	16#-21#	1.6mm-0.8mm
1″ x 1/2″	25.4mm x 12.7mm	16#-20#	1.6mm-0.9mm
1″ x 1″	25.4mm x 25.4mm	14#-21#	2.0mm-0.8mm
11/2″ x 11/2″	38mm x 38mm	14#-19#	2.0mm-1.0mm
1″ x 2″	25.4mm x 50.8mm	14#-16#	2.0mm-1.6mm
2″ x 2″	50.8mm x 50.8mm	12#-16#	2.6mm-1.6mm
