BZD-1100 Automatic Pleating Production Line
US$ 9,000.1 - 12,546.3
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Other, Machinery & Hardware
Packaging Type
Cartons
Packaging Material
Wood
Automatic Grade
Automatic
Driven Type
Electric
Voltage
380v/50Hz
Power
1.1KW
Place of Origin
Hebei, China
Brand Name
rfmesh
Model Number
1250
Certification
GSG
After-sales Service Provided
Overseas service center available
Specifications
1.width:100-500mm2power voltage: 380v/50Hz
3.speed:0-200pleat/min
4.power: 1.1kw
Decoiler 2. Slitting machine 3. Marking machine 4. Pleating Machine
This type of machine is capable for one-layer or multi-layered filter media pleating. It is well designed for filtration media , i.e, impregnated filter paper, glass fiber (HEPA Filters) synthetic media, various types of stainless steel wire mesh as well as combination of fabric and wire mesh duly stitched together. It can also pleat paper card board, copper, aluminium and other metallic foils as may be required.
SLITTING MACHINE 1100 Type
1. Paper feeding speed: 0.5 - 12m/min
2. Width available: 35 - 1100mm
3. Power: 0.75KW 380V
4. Machine weight: 400KG
5. Machine dimension: 1250mm x 680mm x 1120mm
MARKING MACHINE 1100 Type
1. Marking height: 8 - 55mm
2. Width maximum: 1050mm
3. Power: 1.5KW 380V
4. Machine weight: 450KG
5. Machine dimension: 1500mm x 850mm x 1200mm
PLEATING MACHINE 1100 Type
1. Pleating height: 5 - 55mm (or 15 -120mm)
2. Layers pleated: 1 - 5 (Light type and strengthened type)
3. Pleating speed: 20 - 150 pleats/min
4. Max. pleating width : 1100mm
5. Thickness of material: 0.5 - 3mm
6. Speed adjustable motor: 1.5KW
7. Power: 1.5KW 380V Heater Power: 3KW Heat Temperature: 160°C
8. Machine weight: 730KG
9. Machine dimension: 1430mm x 1550mm x 1400mm
1. Paper feeding speed: 0.5 - 12m/min
2. Width available: 35 - 1100mm
3. Power: 0.75KW 380V
4. Machine weight: 400KG
5. Machine dimension: 1250mm x 680mm x 1120mm
MARKING MACHINE 1100 Type
1. Marking height: 8 - 55mm
2. Width maximum: 1050mm
3. Power: 1.5KW 380V
4. Machine weight: 450KG
5. Machine dimension: 1500mm x 850mm x 1200mm
PLEATING MACHINE 1100 Type
1. Pleating height: 5 - 55mm (or 15 -120mm)
2. Layers pleated: 1 - 5 (Light type and strengthened type)
3. Pleating speed: 20 - 150 pleats/min
4. Max. pleating width : 1100mm
5. Thickness of material: 0.5 - 3mm
6. Speed adjustable motor: 1.5KW
7. Power: 1.5KW 380V Heater Power: 3KW Heat Temperature: 160°C
8. Machine weight: 730KG
9. Machine dimension: 1430mm x 1550mm x 1400mm
