7.5 W OEM/ODM Switching Adapter With 6 Types of AC Pug

7.5 W OEM/ODM Switching Adapter With 6 Types of AC Pug thumbnail-1
7.5 W OEM/ODM Switching Adapter With 6 Types of AC Pug thumbnail-2
7.5 W OEM/ODM Switching Adapter With 6 Types of AC Pug thumbnail-3
7.5 W OEM/ODM Switching Adapter With 6 Types of AC Pug photo-1
7.5 W OEM/ODM Switching Adapter With 6 Types of AC Pug photo-2
7.5 W OEM/ODM Switching Adapter With 6 Types of AC Pug photo-3
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
XH
Place of Origin:
China
Model Number:
XH-WA002-S
Contact Supplier Request Quote Chat Now
XunHeng Electronics
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name XH
Place of Origin China
Model Number XH-WA002-S
Output Power 1 - 50W
Output Type Single
Output Current 0.1-1.5A
Output Frequency 50/60Hz(47-63Hz)
Output Voltage 3-30V
Input Voltage 220V

Applications:
Fixed frequency control circuit, apply to mobile phones, electric tools,
laptop computers and iPad, digital cameras, router, POS machine

Product characteristics:

  • Safety approval of CCC, CB, ETL, CE, GS, BS, KC, SAA, PSE

  • Low standby power consumption, meets the energy efficiency standards of EU CoC V5 and US DoE VI/CEC VI (6)

  • Accept customization of specification, USB output type or power cord output type

  • Customization: EU standard, American standard, British standard, Australia standard, Korean Standards, Chinese standard



Electrical characteristics

  • Input voltage: 100-240V AC (90-264V AC)

  • Input current: 0.2A max

  • Frequency: 50/60Hz (47-63Hz)

  • Output voltage: 3.0-30V

  • Output current: 0.1-1.5A

  • No-load power consumption: 0.1W max

  • Efficiency: 70% min

  • Ripple and noises: 50-120mV

  • Line regulation: ±1%

  • Load regulation: ±5%


Output protections:

  • Short circuit protection

  • Over-voltage protection

  • Over-current protection

 Environment-characteristics:

  • Hi-pot test: 3750V AC, 60s 5mA max

  • Insulation resistance: 100MΩ min

  • Leakage current: 0.25mA max

  • Operating temperature: 0 to 40℃

  • Storage humidity: 5-95% RH

  • Burn-in test: rate load, 40 ±5℃, 4 hours

  • EMC standards: EN55022 class B/FCC part 15 class B　

  • EN55024/A1: 2001/EN61000
